SECTION 1 FRAME
S
E
C
T
I
O
N
1
F
R
A
M
E
POTHOLE PROTECTION SYSTEM INSTALLATIONS Ref.
(VARIABLE PARTS)
0255724 1532E/1932E Ref. 7
0255516 2033E Ref. 11
0255638 2046E/2646E Ref. 11
0255639 2658E Ref. 11
51 Bar, Support Options: A/R
4845104 1532E/1932E Prior to S/N 24267 2
4845360 1532E/1932E Right Side S/N 24267 to Present 1
4845383 1532E/1932E Left Side S/N 24267 to Present 1
4845268 2033E Prior to S/N 24267 2
4845357 2033E S/N 24267 to Present 2
4845269 2046E/2646E Prior to S/N 24267 2
4845358 2046E/2646E S/N 24267 to Present 2
4845270 2658E Prior to S/N 24267 2
4845359 2658E S/N 24267 to Present 2
52 Spring, Extension Options: 2
4160134 1532E/1932E/2033E
4160146 2046E/2646E/2658E
53 Rod, Pivot Options: 1
3841308 1532E/1932E
3841266 2033E/2046E/2646E/2658E
54 Actuator Options: 1
4845319 1532E/1932E
4845077 2033E/2046E/2646E/2658E
55 Bar, Actuator Options: 4
0362511 Prior to S/N 31231
0362654 S/N 31231 to Present
56 Switch, Limit Options: 2
56A 4360397 Prior to S/N 31231
56B 4360401 S/N 31231 to Present
FIGURE 1-6. JLG POTHOLE PROTECTION SYSTEM INSTALLATION (POWER DOWN MACHINES)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
