JLG 2658E ANSI Parts Manual User Manual
Page 74
2-20
1532E/1932E 2033E/2046E 2646E/2658E
3120726
SECTION 2 GROUND COMPONENTS
S
E
C
T
I
O
N
2
G
R
O
U
N
D
C
O
M
P
O
N
E
N
T
S
14
Nameplate - Ground Controls Options:
1
3252479
1532E/1932E
3252478
2033E/2046E/2646E/2658E
15
0100076
Silicone - 8lbs Pail (Not Shown-Spread on back of Item 1)
A/R
7016397
Silicone - 5oz Tube (Not Shown-Spread on back of Item 1)
A/R
16
4921986
Harness, Relay (S/N 31685 to Present) (Power Down
1
Machines)
4921990
Harness, Relay (Gravity Down Machines)
1
16A
3740069
Relay (S/N 31685 to Present)
1
17
3911008
Screw #10-24NC x 1" (S/N 31685 to Present)
1
18
4751000
Flatwasher #10 (S/N 31685 to Present)
2
19
3311005
Locknut #10-24NC (S/N 31685 to Present)
1
20
4460259
Terminal (S/N 31685 to Present)
2
21
4460260
Housing, Terminal (S/N 31685 to Present)
2
22
4740479
Washer, Brass 1/4"
6
23
4300133
Stud, Brass 1/4"
3
24
4761400
Lockwasher 1/4"
3
25
3311401
Nut 1/4"-20NC
3
ALARM INSTALLATIONS
Ref.
PRIOR TO AUGUST 1996:
0256682
STANDARD ALARM - 1532E/1932E
Ref.
–
0255951
STANDARD ALARM - 2033E/2046E/2646E/2658E
Ref.
C
AUGUST 1996 TO PRESENT:
0256959
DESCENT ALARM - 1532E/1932E
Ref.
–
0256960
MOTION ALARM - 1532E/1932E
Ref.
–
0256964
TRAVEL ALARM - 1532E/1932E
Ref.
–
0256961
DESCENT ALARM - 2033E/2046E/2646E/2658E
Ref.
–
0256962
MOTION ALARM - 2033E/2046E/2646E/2658E
Ref.
–
0256965
TRAVEL ALARM - 2033E/2046E/2646E/2658E
Ref.
–
101
0140033
Alarm (Remove Ground Strap Before Installation)
1
0641408
Bolt 1/4"-20NC x 1"
2
4711400
Flatwasher 1/4" Narrow
4
3311405
Locknut 1/4"-20NC
2
0256056
HOURMETER GAUGE INSTALLATION - 1532E/1932E
Ref.
4
0256058
HOURMETER GAUGE INSTALLATION - 2033E/2046E/
Ref.
5
2646E/2658E
201
2420165
Gauge, Hourmeter
1
202
2420179
Filter, Hourmeter (Use in-line version in place of bolt-on
1
version when equipped)
0256423
KEY ATTACH INSTALLATION (OPTIONAL)
Ref.
A
301
0641406
Bolt 1/4"-20NC x 3/4"
1
302
4751400
Flatwasher 1/4"
2
303
3311405
Locknut 1/4"-20NC
1
304
1060379
Cable, Lanyard
1
305
3760170
Ring
1
FIGURE 2-6. ELECTRICAL COMPONENTS INSTALLATIONS (AT GROUND CONTROLS)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
