5-16 1532E/1932E 2033E/2046E 2646E/2658E 3120726
SECTION 5 CYLINDERS
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
106 Bushing, Tapered Options: 1
0961896 2033E/2046E
0961897 2646E/2658E
107 Not Used
108 4640509 Cartridge, Valve 1
2900792 Seal Kit - 4640509 Valve 1
109 Capscrew, Socket Head Options: 8
3931620 2033E/2046E Capscrew 3/8"-16NC x 1 1/4"
3931720 2646E/2658E Capscrew 7/16"-14NC x 1 1/4"
110 Ring, Washer Options: 1
3760369 2033E/2046E
3760370 2646E/2658E
111 2220883 Plug, O-Ring 3
112 Kit Wiper 1
113 Kit Seal, Rod 1
114 Kit O-Ring 1
115 Kit Ring, Back-up 1
116 Kit Ring, Wear 1
117 Kit O-Ring 1
118 Kit Ring, Back-up 2
119 Kit Ring, Lock 2
120 Kit Seal 2
121 0100011 Loctite #242 A/R
122 0100038 Primer, Locking A/R
123 Not Used
124 2220885 Plug, O-Ring 1
125 Bolt Options: 3
0630535 2033E/2046E Bolt 1/4"-20NC x 1 1/8"
0641409 2646E/2658E Bolt 1/4"-20NC x 1 1/8"
– – – – – – – – – –
Seal Kit (Includes Items 112-120) 1
2901353 2033E/2046E 1683352 Cylinder
2901273 2646E/2658E 1683363 Cylinder
FIGURE 5-5. LIFT CYLINDER COMPONENTS ASSEMBLY (2033E/2046E POWER DOWN MACHINES
BUILT PRIOR TO S/N 27085 & 2646E/2658E POWER DOWN MACHINES BUILT PRIOR TO S/N 26916)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
