SECTION 1 FRAME
.
FIGURE 1-10. BATTERY CHARGER ASSEMBLIES - STANDARD
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
BATTERY CHARGER ASSEMBLIES
Ref.
Note: Charger Serial Number Nameplate located on front
of charger. First line is the charger spec and date code.
Prior to Mid-February 1996 Example: BA515 (spec) AP
(date code). First letter in the date code indicates month
(A-January/B-February/C-March/etc. with exception of let-
“I” which is not used). Second letter indicates year (S-
T-1996). After Mid-February 1996 Example: BA515 (spec)
9631 (date code). First and second digits in the date code
indicate year. Third and fourth digits indicate week of
manufacture.
0400138
BATTERY CHARGER ASSEMBLY - 60HZ/120V
Ref.
E
(ANSI SPEC)
1
7011502
Transformer
1
2
7011512
Capacitor
1
3
7011560
Strap, Capacitor
1
4
7011576
Diode
2
5
7011596
Varistor
1
6
7011678
Board, Circuit (Prior to April 1996)
1
7018540
Board, Circuit (April 1996 to Present)
1
7011680
Harness - 8 Wire from PC Board
1
7
7011518
Controller, Transformer
1
8
7011517
Triac
1
9
7011687
Cord, DC
1
10
7011688
Cord, AC (Prior to Date Code 9616)
1
11
7011528
Relief, Strain
1
12
7018516
Relief, Strain
1
13
7018525
Breaker, Circuit - AC
1
14
7011509
Breaker, Circuit - DC
1
15
Not Required
16
7011513
Socket, AC (Date Code 9616 to Present)
1
17
7018509
Cover, Case (Not Shown)
1
0400163
BATTERY CHARGER ASSEMBLY - 60HZ/220V
Ref.
A
(ANSI SPEC)
101
7018543
Transformer
1
102
7011512
Capacitor
1
103
7011511
Strap, Capacitor
1
104
7011576
Diode
2
105
7011596
Varistor
1
106
7018542
Board, Circuit
1
7018513
Harness - 8 Wire from PC Board
1
107
7011551
Controller, Transformer
1
108
7011517
Triac
1
109
7011687
Cord, DC
1
110
7018515
Cord, AC
1
111
7011528
Relief, Strain
1
112
7018516
Relief, Strain
1
113
7018514
Breaker, Circuit - AC
1
114
7011509
Breaker, Circuit - DC
1
115 to 116
Not Required
117
Not Available
Cover, Case (Not Shown)
1
