1532E/1932E 2033E/2046E 2646E/2658E
3120726
SECTION 3 SCISSOR ARMS
S
E
C
T
I
O
N
3
S
C
I
S
S
O
R
A
R
M
S
Note: To determine Power or Gravity Down refer to page A.
0256063
ARM CAPS INSTALLATION
Ref.
201
1120474
Cap
4
202
1120475
Cap
4
203
1120472
Cap
4
204
1120473
Cap
12
205
0100080
Adhesive (Not Shown)
A/R
0256509
CABLE/HOSE TRAY INSTALLATION
Ref.
9/G
301
1320224
Clamp, Loop 5/8"
13
302
3941406
Screw, Self-Tapping (Not Shown - Used with Item 2)
8
303
4240018
Tie-Strap 15”/38cm (Not Shown)
12
304
3539264
Tray
1
305
4240125
Strap 4
306
4240128
Strap (S/N 57976 to Present Only)
4
307
4240116
Strap, Mounting Angle
2
308
0641510
Bolt 5/16"-18NC x 1 1/4”
4
309
3311405
Locknut 1/4"-20NC
2
310
3311505
Locknut 5/16"-18NC
4
311
4240033
Tie-Strap 7.5"/19cm (Not Shown)
24
312
4460328
Connector, Strain Relief (Not Shown - Located On Platform)
1
(Prior to S/N 45030)
4460071
Connector, Strain Relief (Not Shown - Located On Platform)
1
(S/N 45030 to Present)
313
4240127
Tie-Strap 21"/53cm (Not Shown)
4
314
4060807
Shield, Trim Edge (Not Shown - Located on Frame)
1ft/30.5m
315
1320095
Clamp (Not Shown)
2
316
0641406
Bolt 1/4"-20NC x 3/4"
2
317
4711500
Flatwasher 5/16" Narrow
8
FIGURE 3-6. SCISSOR ARMS INSTALLATION - 2033E/2046E (GRAVITY DOWN MACHINES)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
