3120726 1532E/1932E 2033E/2046E 2646E/2658E 5-9
SECTION 5 CYLINDERS
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
(Continued)
FIGURE 5-3. LIFT CYLINDER COMPONENTS ASSEMBLY (1532/1932 POWER DOWN MACHINES
BUILT S/N 27181 TO PRESENT)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
Note: To determine Power or Gravity Down refer to
page A.
LIFT CYLINDER SUB-ASSEMBLY Ref.
1 to 22 Not Used
23 0641506 Bolt 5/16"-18NC x 3/4" 4
24 0100011 Loctite #242 A/R
25 4640717 Cartridge, Valve (Manual Descent) 1
26 3311402 Nut, Jam 1/4"-20NC 1
27 0080190 Adapter 1
28 4220044 Stop, Throttle (Prior to S/N 28355 Only) 1
29 0902151 Bracket 1
30 Cable Assembly Options: 1
Use 1060644 Prior to S/N 28175 (was p/n 1060597)
1060644 S/N 28175 to Present
30A 7019602 Bellows Kit (Use with 1060644 Cable Only) 1
30B 7019600 T-Handle (Use with 1060644 Cable Only) 1
31 3450405 Pin, Cotter 1
32 3321402 Nut, Jam 1/4"-28NF 4
33 4711400 Flatwasher 1/4" 4
1683475 LIFT CYLINDER ASSEMBLY - 1532E/1932E Ref. –
101 Kit O-Ring 1
102 Kit Ring, Back-up 1
103 Kit O-Ring 1
104 Kit Wiper 1
105 Kit O-Ring 1
106 Kit Seal 1
107 Kit Seal 1
108 Kit Ring, Wear 2
109 Kit Ring, Wear 1
110 Not Used
111 7017367 Locknut 1
112 7005312 Plug (Not Shown) 1
113 7005315 Plug (Not Shown) 2
114 7005365 Plug 3
115 7017372 Cartridge, Valve 1
Not Available Seal Kit - 7017372 Valve 1
116 Not Serviced Plug 1
117 7017378 Bushing, Garmax 4
118 Not Serviced Barrel Weldment 1
119 7017383 Rod Weldment 1
120 7017382 Head 1
121 7017381 Piston 1
122 7017380 Spacer 1
– – – – – – – – – –
7017379 Seal Kit - 1683475 Cylinder (Includes Items 101-109) 1
