3120726 1532E/1932E 2033E/2046E 2646E/2658E 5-11
SECTION 5 CYLINDERS
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
FIGURE 5-4. LIFT CYLINDER COMPONENTS ASSEMBLY (1532E/1932E GRAVITY DOWN
MACHINES)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
Note: To determine Power or Gravity Down refer to
page A.
LIFT CYLINDER SUB-ASSEMBLY Ref.
1 to 22 Not Used
23 0641506 Bolt 5/16"-18NC x 3/4" 4
24 0100011 Loctite #242 (Not Shown) A/R
25 Cartridge, Valve (Restrictor/Check) Options: 1
4641012 1532E
4641014 1932E
7012953 Seal Kit - 4641012 and 4641014 Cartridges 1
26 4641001 Cartridge, Valve (Solenoid with Manual Descent) 1
7012967 Seal Kit - 4641001 Valve 1
7017444 Solenoid 1
27 0080228 Adapter 1
28 Not Used
29 0902371 Bracket (1532E) (Prior to S/N 43167) 1
0902421 Bracket (1532E) (S/N 43167 to Present) 1
0902151 Bracket (1932E) (Prior to S/N 37703) 1
0902371 Bracket (1932E) (S/N 37703 to S/N 43167) 1
0902421 Bracket (1932E) (S/N 43167 to Present) 1
30 1060644 Cable Assembly 1
30A 7019602 Bellows Kit 1
30B 7019600 T-Handle 1
30C 4220044 Stop, Throttle 1
31 3450405 Pin, Cotter 1
32 3321402 Nut, Jam 1/4"-28NF 4
33 4711400 Flatwasher 1/4" Narrow 4
1683500 LIFT CYLINDER ASSEMBLY - 1532E/1932E Ref. A
101 Kit O-Ring 1
102 Kit Ring, Back-up 1
103 Kit O-Ring 1
104 Kit Wiper 1
105 Kit O-Ring 1
106 Kit Seal 1
107 Kit Seal 1
108 Kit Ring, Lock 2
109 Kit Ring, Wear 1
110 Not Used
111 7017367 Locknut 1
112 7005358 Plug 2
113 7019803 Plug 1
114 7019302 Plug 2
115 7017378 Bushing, Garmax 4
