3120726 1532E/1932E 2033E/2046E 2646E/2658E 2-19
SECTION 2 GROUND COMPONENTS
S
E
C
T
I
O
N
2
G
R
O
U
N
D
C
O
M
P
O
N
E
N
T
S
FIGURE 2-6. ELECTRICAL COMPONENTS INSTALLATIONS (AT GROUND CONTROLS)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
GROUND CONTROLS INSTALLATION
0255971 1532E/1932E Standard Machines Prior to S/N 49391 Ref. 12
0258782 1532E/1932E Standard Machines S/N 49391 to Present Ref. 1
0256918 1532E/1932E U/L Machines Prior to S/N 49391 Ref. 4
0258784 1532E/1932E U/L Machines S/N 49391 to Present Ref. 1
0255960 2033E/2046E/2646E/2658E Standard Machines without Ref. 7
Power Deck Prior to S/N 49391
0258785 2033E/2046E/2646E/2658E Standard Machines without Ref. 1
Power Deck S/N 49391 to Present
0257599 2033E/2046E/2646E/2658E Standard Machines with Ref. 6
Power Deck Prior to S/N 49391
0258788 2033E/2046E/2646E/2658E Standard Machines with Ref. 1
Power Deck S/N 49391 to Present
0256858 2033E/2046E/2646E/2658E U/L Machines without Ref. 4
Power Deck Prior to S/N 49391
0258787 2033E/2046E/2646E/2658E U/L Machines without Ref. 1
Power Deck S/N 49391 to Present
0257600 2033E/2046E/2646E/2658E U/L Machines with Ref. 3
Power Deck Prior to S/N 49391
0258789 2033E/2046E/2646E/2658E U/L Machines with Ref. 1
Power Deck S/N 49391 to Present
1 Controller, SMART System TM Options: 1
1600233 Prior to S/N 29221
1600258 S/N 29221 to S/N 49391
1600286 S/N 49391 to Present
Note: When replaced, controller must be configured to
appropriate model and options using analyzer kit p/n
2901443 or computer software kit p/n 2900874.
2 0641406 Bolt 1/4"-20NC x 3/4" 4
3 4751400 Flatwasher 1/4" A/R
4 0100020 Sealant A/R
5 Relay Options: 1
Use 3740130 Standard Machine Prior to S/N 30199 (was p/n 3740117)
Use 3740130 Standard Machine S/N 30199 to S/N 44433 (was p/n
3740120)
3740130 Standard Machine (S/N 44433 to Present)
3740117 Standard Machines without 1600286 Controller Operated
in Cold Weather Regions
3740121 U/L Machine
6 Not Used
7 3311405 Locknut 1/4”-20NC A/R
8 Cable Assembly Options: 1
1060606 1532E/1932E
4460618 Connector, Anderson 2
Not Required 2033E/2046E/2646E/2658E
9 4360070 Breaker, Circuit 1
10 4360432 Switch, Keyed Select 1
7019604 Switch Kit (Includes o-rings, boot and locking ring) 1
10A 2860030 Key, Replacement 1
11 4360328 Switch, Toggle A/R
12 4360395 Switch, Emergency Stop (Prior to S/N 44433) 1
12A 7016315 Cap 1
12 4360289 Switch, Emergency Stop (S/N 44433 to Present) 1
12A 7012612 Boot 1
13 Not Used
