JLG 2658E ANSI Parts Manual User Manual
Page 27

3120726
1532E/1932E 2033E/2046E 2646E/2658E
1-19
S
E
C
T
I
O
N
1
F
R
A
M
E
SECTION 1 FRAME
.
FIGURE 1-5. AXLE/BRAKE INSTALLATIONS (GRAVITY DOWN MACHINES)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
Note: To determine Power or Gravity Down refer to Page A.
BRAKE INSTALLATION (STANDARD PARTS)
Ref.
1
2780215
Hub Assembly (See Items 101-113 for Breakdown)
2
2
Not Used
3
4845037
Cam, Brake
2
4
3430620
Pin, Clevis
2
5
4711600
Flatwasher 3/8" Narrow
2
6
3450403
Pin, Cotter
2
7
1683557
Brake Cylinder Assembly (See Section 5 for Breakdown)
1
8
4160137
Spring
2
9
3300255
Lugnut
5
BRAKE INSTALLATIONS (VARIABLE PARTS)
Ref.
0257183
1532E/1932E
Ref.
3
0257184
2033E
Ref.
3
0257185
2046E/2646E
Ref.
2
0257186
2658E
Ref.
2
51
Rod, Brake Options:
2
3841332
1532E/1932E/2033E
3841333
2046E/2646E
3841334
2658E
52
Spacer Options:
A/R
Not Required
1532E/1932E/2033E
Not Required
2046E/2646E/2658E Prior to S/N35949
4567265
2046E/2646E/2658E S/N35949 to Present
2780215
HUB ASSEMBLY
Ref.
B
101
7010649
Seal
1
102
7019695
Housing
1
103
7019696
Stud, Wheel
5
104
Not Used
105
7019697
Washer
1
106
7010641
Nut, Slotted
1
107
7010642
Pin, Cotter
1
108
7010648
Cap, Dust
1
109
7010646
Cone, Outer
1
110
7010650
Cup, Outer
1
111
7010651
Cup, Inner
1
112
7010647
Cone, Inner
1
113
1760165
Disc, Brake
1
ASSOCIATED FRAME COMPONENTS
Ref.
201
Axle Weldment Options:
1
0280145
1532E/1932E/2033E
0280146
2046E/2646E
0280147
2658E
