3120726 1532E/1932E 2033E/2046E 2646E/2658E 3-19
SECTION 3 SCISSOR ARMS
S
E
C
T
I
O
N
3
S
C
I
S
S
O
R
A
R
M
S
.
FIGURE 3-5. SCISSOR ARMS INSTALLATION - 2033E/2046E (POWER DOWN MACHINES)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
0255571 COMMON MACHINES Ref. 11
0256381 CANADIAN MACHINES Ref. 8
Note: To determine Power or Gravity Down refer to page A.
1 Not Used
2 0200531 Arm Weldment (Top and Bottom Inboard) 2
3 0200532 Arm Weldment (Mid Inboard) 1
4 0200533 Arm Weldment (Top and Bottom Outboard) 2
5 0200534 Arm Weldment (Mid Outboard) 2
6 3422483 Pin 5
7 3422484 Pin 2
8 3422485 Pin 2
9 to 10 Not Used
11 3422488 Pin 2
12 Lift Cylinder Assembly (See Section 5 for Breakdown) 1
1683352 Prior to S/N27085
1683473 S/N27085 to Present
13 3340784 Pad, Slide Block (Prior to S/N 29022) 4
3340629 Pad, Slide Block (S/N 29022 to Present) 4
14 Not Used
15 4740438 Washer, Special 14
16 3760387 Ring, Retaining 14
17 0641522 Bolt 5/16"-18NC x 2 3/4" 2
18 4711500 Flatwasher 5/16" Narrow 8
19 4751500 Flatwasher 5/16" Regular 8
20 3311505 Locknut 5/16"-18NC 24
21 Not Used
22 0681520 Bolt 5/16"-18NC x 2 1/2" Grade 8 12
23 to 33 Not Used
34 0962010 Bushing, Garmax (4 Per Weldment) 8
35 0962010 Bushing, Garmax (3 Per Weldment) 6
36 Not Used
37 4845040 Prop, Safety (Prior to S/N 28355) 1
4845431 Prop, Safety (S/N 28355 to Present) 1
38 0641508 Bolt 5/16"-18NC x 1" 2
39 Not Used
40 3340645 Pad 3
41 0962015 Bushing, Split (Prior to S/N 28355) 1
4240125 Bushing, Split (S/N 28355 to Present) 1
42 3422483 Pin (Common) 1
3422587 Pin (Canada Only) 1
43 0641524 Bolt 5/16"-18NC x 3" 8
44 4240114 Strap (Prior to S/N 28355) 1
4240128 Strap (S/N 28355 to Present) 1
– – – – – – – – – –
2901340 Arm Kit - 2033E/2046E (Includes Items 2-5 & 37) 1 A
0252586 ARM PADS INSTALLATION Ref. –
101 3340645 Pad 16
