1-38 1532E/1932E 2033E/2046E 2646E/2658E 3120726
SECTION 1 FRAME
S
E
C
T
I
O
N
1
F
R
A
M
E
914 4460320 Housing, Terminal 1
915 4460268 Socket, Terminal 2
916 0100011 Loctite #242 (Not Shown) A/R
0257266 TIE-DOWNS INSTALLATION Ref. 2/A
1001 3760365 D-Ring 2
1002 0630485 Bolt, Carriage 3/8"-16NC x 1" (2 per Tie-Down) 4
1003 4751600 Flatwasher 3/8" (2 per Tie-Down) 4
1004 3311605 Locknut 3/8"-16NC (2 per Tie-Down) 4
FIGURE 1-9. FRAME MOUNTED COMPONENTS INSTALLATION (GRAVITY DOWN MACHINES)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
