SECTION 6 - JLG CONTROL SYSTEM
6-104
– JLG Lift –
3121171
MA1 CAL L (X)
Displays the lowest main angle #1 value recorded during calibration
MA2 CAL L (X)
Displays the lowest main angle #2 value recorded during calibration
MA1 CAL H (X)
Displays the highest main angle #1 value recorded during calibration
MA2 CAL H (X)
Displays the highest main angle #2 value recorded during calibration
TRIP ANG (X.X)
Displays the length of the tower recorded at the transport trip point during
calibration
TWR CYL: LONG
Displays type of cylinder installed on machine
CALIBRATION DATA:
LOAD ZERO (X)
Displays the value of the moment pin recorded during calibration
LOAD 500LB (X)
Displays the value of the moment pin recorded during calibration
BASKET UP (X)
Displays the value of the basket up crack point recorded during calibration
BASKET DOWN (X)
Displays the value of the basket down crack point recorded during calibra-
tion
L FWD DRIVE (XXXX)
Displays the value of the left forward drive crack point recorded during cal-
ibration
R FWD DRIVE (XXXX)
Displays the value of the right forward drive crack point recorded during
calibration
L REV DRIVE (XXXX)
Displays the value of the left reverse drive crack point recorded during cal-
ibration
R REV DRIVE (XXXX)
Displays the value of the right reverse drive crack point recorded during
calibration
F LT STEER (XXXX)
Displays the value of the front left steer crack point recorded during cali-
bration
F RT STEER (XXXX)
Displays the value of the front right steer crack point recorded during cali-
bration
R LT STEER (XXXX)
Displays the value of the rear left steer crack point recorded during cali-
bration
R RT STEER (XXXX)
Displays the value of the rear right steer crack point recorded during cali-
bration
M LIFT UP (XXXX)
Displays the value of the main lift up crack point recorded during calibra-
tion
M LIFT DOWN (XXXX)
Displays the value of the main lift down crack point recorded during cali-
bration
M TELE IN (XXXX)
Displays the value of the main telescope in crack point recorded during
calibration
M TELE OUT (XXXX)
Displays the value of the main telescope out crack point recorded during
calibration
BM ANG 1 LO (X)
Displays the low value boom angle recorded from sensor 1 during calibra-
tion
Table 6-7. Analyzer Diagnostics Menu
Menu:
Submenu:
Selection:
Description:
