SECTION 6 - JLG CONTROL SYSTEM
6-28 – JLG Lift – 3121171
TOWER TELESCOPE:
ACCEL X.Xs
Displays/adjusts tower telescope acceler-
ation
1.0 to 1.0 sec 1.0
DECEL X.Xs
Displays/adjusts tower telescope deceler-
ation
0.5 to 0.5 sec 0.5
MIN IN XX%
Displays/adjusts minimum tower tele-
scope in speed. Same as Creep speed
1 to 1% 1
MAX IN XXX%
Displays/adjusts maximum tower tele-
scope in speed
60 to 60% 60
MIN OUT XX%
Displays/adjusts minimum tower tele-
scope out speed. Same as Creep speed
1 to 1% 1
MAX OUT XXX%
Displays/adjusts maximum tower tele-
scope out speed
60 to 60% 60
BASKET LEVEL:
ACCEL X.Xs Displays/adjusts basket level acceleration 0.1 to 5.0 sec 1.5
DECEL X.Xs Displays/adjusts basket level deceleration 0.1 to 3.0 sec 0.5
MIN UP XX%
Displays/adjusts minimum basket level up
speed. Same as Creep speed
0 to 65% 40
MAX UP XXX%
Displays/adjusts maximum basket level
up speed
0 to 100% 70
MIN DOWN XX%
Displays/adjusts minimum basket level
down speed. Same as Creep speed
0 to 65% 40
MAX DOWN XXX%
Displays/adjusts maximum basket level
down speed
0 to 100% 70
BASKET ROTATE:
ACCEL X.Xs
Displays/adjusts basket rotate accelera-
tion
0.1 to 5.0 sec 1.0
DECEL X.Xs
Displays/adjusts basket rotate decelera-
tion
0.1 to 3.0 sec 0.5
MIN LEFT XX%
Displays/adjusts minimum basket rotate
left speed. Same as Creep speed
0 to 100% 60
MAX LEFT XXX%
Displays/adjusts maximum basket rotate
left speed
0 to 100% 60 24-30 (180)
MIN RIGHT XX%
Displays/adjusts minimum basket rotate
right speed. Same as Creep speed
0 to 100% 60
MAX RIGHT XXX%
Displays/adjusts maximum basket rotate
right speed
0 to 100% 60 24-30 (180)
JIB LIFT:
ACCEL X.Xs Displays/adjusts jib lift acceleration 0.1 to 5.0 sec 1.5
DECEL X.Xs Displays/adjusts jib lift deceleration 0.1 to 3.0 sec 1.0
MIN UP XX%
Displays/adjusts minimum jib up speed.
Same as Creep speed
0 to 65% 40
MAX UP XXX% Displays/adjusts maximum jib up speed 0 to 100% 65 30-36
MIN DOWN XX%
Displays/adjusts minimum jib down
speed. Same as Creep speed
0 to 65% 40
MAX DOWN XXX%
Displays/adjusts maximum jib down
speed
0 to 100% 60 30-36
Table 6-4. Machine Personality Settings and Speeds
