SECTION 6 - JLG CONTROL SYSTEM
6-26 – JLG Lift – 3121171
Table 6-4. Machine Personality Settings and Speeds
Submenu
(Displayed on
Analyzer 1st
Line)
Parameter
(Displayed on Analyzer 2
nd
Line)
Description Range
DEFAULT
VALUES
TIME RANGE
(SEC) (SEE
Section 6.9
FOR MACHINE
ORIENTATION
WHENSETTING
SPEEDS)
DRIVE:
ACCEL X.Xs Displays/adjusts drive acceleration 0.1 to 5.0 sec 2.0
DECEL X.Xs Displays/adjusts drive deceleration 0.1 to 3.0 sec 1.3
MIN forward XX%
Displays/adjusts minimum forward drive
speed
0 to 35% 1
MAX forward XXX%
Displays/adjusts maximum forward drive
speed
0 to 100% 100
40-48 (see
orientation)
MIN reverse XX%
Displays/adjusts minimum reverse drive
speed
0 to 35% 1
MAX reverse XXX%
Displays/adjusts maximum reverse drive
speed
0 to 100% 100
40-48 (see
orientation)
ELEV. MAX XX%
Displays/adjusts maximum drive speed
NOTE: used when elevation cutout
switches are limiting maximum speed
0 to 50% 25
93-104 (see
orientation)
CREEP MAX XX%
Displays/adjusts maximum drive speed
NOTE: used when creep switch on pump
pot is active
0 to 50% 35
79-87 (see
orientation)
STEER:
max SPEED XXX% Displays/adjusts maximum steer speed. 0 to 100% 100
MAIN LIFT:
ACCEL X.Xs Displays/adjusts main lift acceleration 0.1 to 5.0 sec 1.0
DECEL X.Xs Displays/adjusts main lift deceleration 0.1 to 3.0 sec 1.0
MIN Up XX%
Displays/adjusts minimum main lift up
speed
0 to 60% 1
MAX UP XX%
Displays/adjusts maximum main lift up
speed
0 to 60% 60
57-69 (see
orientation)
CREEP UP XX%
Displays/adjusts maximum main lift up
speed
NOTE: used when creep switch on pump
pot is active
0 to 65% 35
MIN DOWN XX%
Displays/adjusts minimum main lift down
speed
0 to 60% 1
MAX DOWN XXX%
Displays/adjusts maximum main lift down
speed
0 to 60% 60
59-70 (see
orientation)
CREEP DOWN XX%
Displays/adjusts maximum main lift down
speed
NOTE: used when creep switch on pump
pot is active
0 to 75% 35
