SECTION 6 - JLG CONTROL SYSTEM
3121171 – JLG Lift – 6-103
ENVELOPE SENSORS:
TWR LEN1 (X.X)" Displays the measured value of tower length sensor #1
TWR LEN2 (X.X)" Displays the measured value of tower length sensor #2
TWR ANGL1 (XX.X) Displays the measured value of tower angle sensor #1
TWR ANGL2 (XX.X) Displays the measured value of tower angle sensor #2
CYL ANGL (XX.X) Displays the measured value of cylinder angle sensor #2
MN ANGL1 (XX.X) Displays the measured value of main angle sensor #1 to the tower
MN ANGL2 (XX.X) Displays the measured value of main angle sensor #2 to the tower
TO GRAV MN ANGL L (XXXX) Displays the measured value of lowest value main angle sensor to gravity
TO GRAV MN ANGL H (XXXX) Displays the measured value of largest value main angle sensor to gravity
A/D T LEN1 (X) Displays the analog to digital counts of tower length sensor #1
A/D T LEN2 (X) Displays the analog to digital counts of tower length sensor #2
A/D ANG1 (XX.X) Displays the analog to digital counts of tower angle sensor #1
A/D ANG2 (XX.X) Displays the analog to digital counts of tower angle sensor #2
A/D CYL (X) Displays the analog to digital counts of cylinder angle sensor
MN ANG A/D SNSR1 (XXXX) Displays the analog to digital counts of main angle sensor #1
MN ANG A/D SNSR2 (XXXX) Displays the analog to digital counts of main angle sensor #2
MN ANG RAW SNSR1 (X.X) Displays the raw value of main angle sensor #1
MN ANG RAW SNSR2 (X.X) Displays the raw value of main angle sensor #2
RET LEN 1 (X) displays the retracted length of the tower found by sensor #1 during cali-
bration
RET LEN 2 (X) displays the retracted length of the tower found by sensor #2 during cali-
bration
EXT LEN 1 (X) displays the extended length of the tower found by sensor #1 during cali-
bration
EXT LEN 2 (X) displays the extended length of the tower found by sensor #2 during cali-
bration
TRIP LEN (XXXX.X) Displays the length of the tower recorded at the transport trip point during
calibration
TA1 CAL L (X.X) Displays the lowest tower angle #1 value recorded during calibration
TA2 CAL L (X.X) Displays the lowest tower angle #2 value recorded during calibration
TA1 CAL H (X.X) Displays the highest tower angle #1 value recorded during calibration
TA2 CAL H (X.X) Displays the highest tower angle #2 value recorded during calibration
CYL CAL L (X) Displays the lowest cylinder angle value recorded during calibration
CYL CAL H (X) Displays the highest cylinder angle value recorded during calibration
Table 6-7. Analyzer Diagnostics Menu
Menu: Submenu: Selection: Description:
