8-27 G6-42A, G9-43A, G10-43A
Hydraulic System
8.8.5 Cylinder Torque Specifications—G9-43A & G10-43A
a. Extend/Retract Cylinder
b. Tilt Cylinder
c. Compensation Cylinder
d. Frame Level Cylinder
e. Outrigger Cylinder (G10-43A)
Head Nut Valve
300-400 lb-ft (407-542 Nm) 745-825 lb-ft (1010-1119 Nm)
Apply Loctite 271
105-115 lb-ft (142-156 Nm)
Nut Valve
1125-1375 lb-ft (1525-1864 Nm) 44 lb-ft (60 Nm)
Nut
1125-1375 lb-ft (1525-1864 Nm)
Head Nut Set Screws
300-400 lb-ft (407-542 Nm) 720-800 lb-ft (976-1085 Nm)
Apply Loctite 271
.4 lb-ft (.5 Nm)
Apply Loctite 243
Piston Head Set Screws Check Valve
2350-2600 lb-ft (3186-3525 Nm)
Apply Loctite 271
300-400 lb-ft (407-542 Nm) .4 lb-ft (.5 Nm)
Apply Loctite 243
30-35 lb-ft (41-47 Nm)
