Electrical System
9-40 G6-42A, G9-43A, G10-43A
221 108 3 Amber
Barometric
Pressure
Barometric Pressure Sensor Circuit—Voltage Above
Normal, or Shorted to High Source
222 108 4 Amber
Barometric
Pressure
Barometric Pressure Sensor Circuit—Voltage Below
Normal, or Shorted to Low Source
227 3510 3 Amber
5 Volts
DC Supply
Sensor Supply Voltage #2 Circuit—Voltage Above
Normal, or Shorted to High Source
234 190 0 Red Engine Speed
Engine Speed High—Data Valid but Above Normal
Operational Range—Most Severe Level
235 111 1 Red Coolant Level
Coolant Level Low—Data Valid but Below Normal
Operational Range—Most Severe Level
237 644 2 Amber
External Speed
Input
External Speed Input (Multiple Unit Synchronization)
—Data Erratic, Intermittent, or Incorrect
238 3511 4 Amber
System code # 1
Diagnostic
Sensor Supply Voltage #3 Circuit—Voltage Below
Normal, or Shorted to Low Source
239 3511 3 Amber
System code #2
Diagnostic
Sensor Supply Voltage #3 Circuit—Voltage Above
Normal, or Shorted to High Source
241 84 2 Amber
Wheel-based
Vehicle Speed
Vehicle Speed Sensor Circuit—Data Erratic,
Intermittent, or Incorrect
242 84 10 Amber
Wheel-based
Vehicle Speed
Vehicle Speed Sensor Circuit tampering has been
detected—Abnormal Rate of Change
244 623 4 Amber Red Stop Lamp
Red Stop Lamp Driver Circuit—Voltage Below
Normal, or Shorted to Low Source
245 647 4 Amber
Fan Clutch
Output Device
Driver
Fan Control Circuit—Voltage Below Normal, or
Shorted to Low Source
271 1347 4 Amber
Fuel Pump
Pressurizing
Assembly #1
High Fuel Pressure Solenoid Valve Circuit—Voltage
Below Normal, or Shorted to Low Source
272 1347 3 Amber
Fuel Pump
Pressurizing
Assembly #1
High Fuel Pressure Solenoid Valve Circuit—Voltage
Above Normal, or Shorted to High Source
285 639 9 Amber Datalink
Multiplexing PGN Timeout Error—Abnormal
Update Rate
286 639 13 Amber Datalink Multiplexing Configuration Error—Out of Calibration
Fault
Codes
SPN
Codes
FMI
Codes
Lamp
Color
SPN
Description
Cummins Description
