Electrical System
9-32 G6-42A, G9-43A, G10-43A
2357 Auxiliary Hydraulic Joystick -
Out Of Range High
• Auxiliary Hydraulic A & B prevented
• The auxiliary joystick analog voltage was
measured to be greater than 4.85V. Auxiliary
hydraulics will be prevented until the next power
cycle. This fault may be caused by improper
wiring, a joystick issue or a control module issue.
• Active when Machine Setup’s AUX HYDRAULIC is
set to ENABLED
Yes
2358 Auxiliary Hydraulic Joystick -
Out Of Range Low
• Auxiliary Hydraulic A & B prevented
• The auxiliary joystick’s analog voltage was
measured to be less than 0.15V. Auxiliary
hydraulics will be prevented until the next power
cycle.
• Active when Machine Setup’s AUX HYDRAULIC is
set to ENABLED
Yes
2397 Fork Tilt Joystick -
Voltage Disagreement
• Fork Tilt Up & Down prevented
• Analog feedback from the joystick’s tilt roller did
not agree within ±25% for 1000mS. Fork tilt up and
down will be prevented until the next power cycle.
This fault may be caused by improper wiring, a
joystick issue or a control module issue.
Yes
2398 Fork Tilt Joystick -
Out Of Range High
• Fork Tilt Up & Down prevented
• Analog feedback from the joystick’s tilt roller was
measured to be greater than 4.85V. Fork tilt up and
down will be prevented until the next power cycle.
This fault may be caused by improper wiring, a
joystick issue or a control module issue.
Yes
2399 Fork Tilt Joystick -
Out Of Range Low
• Fork Tilt Up & Down prevented
• Analog feedback from the joystick’s tilt roller was
measured to be less than 0.15V. Fork tilt up and
down will be prevented until the next power cycle.
This fault may be caused by improper wiring, a
joystick issue or a control module issue.
Yes
33191 Fork Tilt Valve -
Open Circuit
• The desired current is greater than 250mA, but the
actual current is less then 75mA
• The fork tilt up digital output was open-circuit. This
fault may be caused by improper wiring or a
control module issue.
Yes
DTC Event Comment Latched
