9-45 G6-42A, G9-43A, G10-43A
Electrical System
1852 97 16 Amber
Water in Fuel
Indicator
Water in Fuel Indicator—Data Valid but Above
Normal Operational Range—Moderately
Severe Level
1896 2791 13 Amber Not Available EGR Valve Controller—Out of Calibration
1911 157 0 Amber
Injector
Metering Rail
Injector Metering Rail 1 Pressure—Data Valid
but Above Normal Operational Range—Most
Severe Level
1938 3597 18 Amber Not Available
ECU Power Output Supply Voltage 1—Data Valid
But Below Normal Operating Range—Moderately
Severe Level
1939 3597 3 Amber Not Available
ECU Power Output Supply Voltage 1—Voltage
Above Normal, or Shorted to High Source
1941 3597 4 Amber Not Available
ECU Power Output Supply Voltage 1—Voltage
Below Normal, or Shorted to Low Source
1942 101 2 Amber Not Available
Crankcase Pressure—Data Erratic, Intermittent
or Incorrect
1974 101 15
Amber/
Blink-
ing
Not Available
Crankcase Pressure—Data Valid But Above Normal
Operating Range—Least Severe Level
2185 3512 3
Sensor Supply 4 Circuit—Voltage above normal, or
shorted to high source
2186 611 4 Amber
System code # 1
Diagnostic
Sensor Supply 4 Circuit—Voltage Below Normal, or
Shorted to Low Source
2195 703 14
Auxiliary Equipment Sensor Input 3 Engine
Protection Critical—Special Instructions
2249 157 1 Amber
Injector
Metering Rail
1 Pressure
Injector Metering Rail 1 Pressure—Data Valid
but Below Normal Operational Range—Most
Severe Level
2272 27 4 Amber Not Available
EGR Valve Position Circuit—Voltage Below Normal,
or Shorted to Low Source
2288 103 15 None Not Available
Turbocharger 1 Speed—Data Valid But Above
Normal Operating Range—Least Severe Level
2311 633 31 Amber
Fuel Control
Valve #1
Fueling Actuator #1 Circuit Error—Condition Exists
Fault
Codes
SPN
Codes
FMI
Codes
Lamp
Color
SPN
Description
Cummins Description
