Hydraulic System
8-2 G6-42A, G9-43A, G10-43A
8.1 HYDRAULIC COMPONENT
TERMINOLOGY
To understand the safety, operation and service
information presented in this section, it is necessary that
the operator/mechanic be familiar with the name and
location of the hydraulic components of the machine. The
following illustration identifies the components that are
referred to throughout this section.
8.1.1 G6-42A Components
MY8090
TILT
CYLINDER
FRAME LEVEL
CYLINDER
LIFT/LOWER
CYLINDER
HYDRAULIC FLUID
RESERVOIR
COMPENSATION
CYLINDER
EXTEND/RETRACT
CYLINDER
(INSIDE BOOM)
MAIN CONTROL
VALVE
PRIORITY
VALVE
