G6-42A, G9-43A, G10-43A
Electrical System
288
974
19
Red
Remote
Accelerator
Multiplexing Remote Accelerator Pedal or Lever
Data Error—Received Network Data In Error
292
441
14
Red
Auxiliary
Temperature 1
Auxiliary Temperature Sensor Input 1
—Special Instructions
293
441
3
Amber
OEM
Temperature
Auxiliary Temperature Sensor Input # 1 Circuit
—Voltage Above Normal, or Shorted to High Source
294
441
4
Amber
OEM
Temperature
Auxiliary Temperature Sensor Input # 1 Circuit
—Voltage Below Normal, or Shorted to Low Source
295
108
2
Amber
Barometric
Pressure
Barometric Pressure Sensor Circuit—Data Erratic,
Intermittent, or Incorrect
296
1388
14
Red
Auxiliary
Pressure
Auxiliary Pressure Sensor Input 1
—Special Instructions
322
651
5
Amber
Injector
Cylinder #01
Injector Solenoid Cylinder #1 Circuit
—Current Below Normal, or Open Circuit
324
653
5
Amber
Injector
Cylinder #03
Injector Solenoid Cylinder #3 Circuit—Current Below
Normal, or Open Circuit
331
652
5
Amber
Injector
Cylinder #02
Injector Solenoid Cylinder #2 Circuit—Current Below
Normal, or Open Circuit
332
654
5
Amber
Injector
Cylinder #04
Injector Solenoid Cylinder #4 Circuit—Current Below
Normal, or Open Circuit
343
629
12
Amber
Controller #1
Engine Control Module Warning internal hardware
failure—Bad Intelligent Device or Component
349
191
16
Amber
Transmission
Output Shaft
Speed
Transmission Output Shaft Speed—Data Valid but
Above Normal Operational Range—Moderately
Severe Level
351
627
12
Amber
Controller #1
Injector Power Supply—Bad Intelligent Device
or Component
352
3509
4
Amber
5 Volts DC Sup-
ply
Sensor Supply Voltage #1 Circuit—Voltage Below
Normal, or Shorted to Low Source
386
3509
3
Amber
5 Volts DC Sup-
ply
Sensor Supply Voltage #1 Circuit—Voltage Above
Normal, or Shorted to High Source
415
100
1
Red
Engine Oil
Pressure
Oil Pressure Low—Data Valid but Below Normal
Operational Range—Most Severe Level
Fault
Codes
SPN
Codes
FMI
Codes
Lamp
Color
SPN
Description
Cummins Description
