Cab and Covers
4-2
G6-42A,G9-43A, G10-43A
4.1
OPERATOR CAB AND COVERS
COMPONENT TERMINOLOGY
To understand the safety, operation and maintenance
information presented in this section, it is necessary that
the operator/mechanic be familiar with the names and
locations of the major assemblies of the machine cab and
covers. The following illustration identifies the
components that are referred to throughout this section.
4.1.1
General Overview—G6-42A/G9-43A
MY7700
TRANSMISSION
CONTROL LEVER
INSTRUMENT PANEL
STEERING WHEEL
FRAME LEVEL
INDICATOR
BOOM CONTROL
JOYSTICK
FRAME LEVEL JOYSTICK
AND ATTACHMENT TILT
(IF EQUIPPED)
ACCELERATOR
PEDAL
SERVICE BRAKE
PEDAL
IGNITION
SWITCH
ACCESSORY
CONTROL LEVER
(IF EQUIPPED)
AUXILIARY
HYDRAULIC
JOYSTICK
(G6-42A)
AUXILARY
HYDRAULIC
JOYSTICK
(G9-43A)
RIGHT HAND
PANEL
DECOMPRESSION VALVE
(G9-43A IF EQUIPPED)
