■ Bolts and fasteners
Visually inspect all fasteners to see that none is
missing or obviously loose.
Pay particular attention to all of the pin caps (1)
and snap rings (2) that connect the booms,
they should all be present and not damaged in
any way.
Check the turntable end of the booms and the
end of the lift cylinders for other pin caps and
snap rings.
Check both sides of the machine.
Pay particular attention to all of the wheel nuts
and bolts.
None should be visibly loose, missing, or
deformed.
Pay particular attention to all of the upper rotation
bearing bolts.
None should be visibly loose, missing, nor have
broken heads.
Pay particular attention to all of the lower, (view
from under the machine), rotation bearing bolts.
None should be visibly loose, missing, nor have
broken heads.
page 7 - 4 AB46J – 0163187
7. Daily Inspection and Maintenance
