■ Electronic Display Message Tables
The following tables list the four types of
messages that the Electronic Display will indicate
and an explanation of each message.
page 6 - 6 AB46J – 0163187
6. Controls
Electronic display message: Explanation of message:
This is the first message to appear after the platform control
box is turned on. This message indicates the drive system
electrical circuits are operating correctly and will only be
displayed a few seconds, then the CLOSE FOOT SWITCH
message will appear.
This is the second message to appear during the DRIVE
SYSTEM check. It tells the operator that the platform foot
switch must be closed (stepped on), to allow the system to
check the condition of the battery.
The third message will indicate that in neutral position the drive
velocity is 0.0 MPH and will show the state of charge of the
batteries. The second line reads like an automobile fuel gauge.
If all 10 indicator box's are lit, the batteries are at full (F)
charge. If no indicator box's are lit, the batteries are fully
discharged. The drive system cannot be operated until this
message appears.
After the NEUTRAL message is displayed and you push the
Drive/Steer controller to FORWARD, this message appears. It
tells you the direction of travel along the ground, the VELOCITY
(speed in mph) of travel and the BATTERY condition.
After the NEUTRAL message is displayed and you push the
Drive/Steer controller to REVERSE, this message appears. It
tells you the direction of travel along the ground, the VELOCITY
(speed in mph) of travel and the BATTERY condition.
❑
Information message table
DRIVE SYSTEM CHECK
***SYSTEM OK!***
Electronic display message: Explanation of message:
Either WAIT message will automatically clear itself after the
component cools to normal operating temperature.
If the component repeatedly overheats, notify a qualified
service technician about the problem.
❑
Wait message table
CLOSE FOOT SWITCH
TO TEST BATTERY
NEUTRAL VEL = 0.0 MPH
BATT E
F
FORWARD VEL = _._ MPH
BATT E
F
REVERSE VEL = _._ MPH
BATT E
F
WAIT - CNTRL COOLING
MOTOR CNTRL OVERTEMP
WAIT - MOTOR COOLING
MOTOR OVERTEMP
