6. Controls
Electronic display message: Explanation of message:
This message occurs immediately after the system diagnostic
has been performed if the Drive/Steer joystick controller is not
centered. Move the controller to its center position and remove
your foot from the foot switch. The CLOSE FOOT SWITCH
message should then appear.
This message occurs when you are trying to drive in
FORWARD but have forgotten to step on the foot switch before
pushing the Drive/Steer joystick controller. Move the controller
to its center position, release the foot switch, then step on the
foot switch before you move the Drive/Steer joystick controller
to FORWARD.
This message occurs when you are trying to drive in REVERSE
but have forgotten to step on the foot switch before pushing the
Drive/Steer joystick controller. Move the controller to its center
position, release the foot switch, then step on the foot switch
before you move the Drive/Steer joystick controller to
REVERSE.
The AB46J automatically stops when its ground speed in 1 mph
over the speed determined by the Drive/Steer joystick
controller setting. This action prevents the AB46J from "running
away" down steep grades. Release the controller then slowly
move it the direction you want to go.
Battery voltage is too low for normal operation.
Remove the AB46J from service, set the Battery switch to
OFF, and follow the battery charging instructions in this manual
or on the decal at the front of the chassis.
Reverse the direction of travel to get off the incline.
Find a different route to get where you were going.
This message appears when the foot switch has been closed
for over 30 seconds but no attempt has been made to drive the
machine. Release the foot switch.
DO NOT step on the foot switch until you are ready to use a
control on the platform control box.
❑
Operator Action message table
CENTER JOYSTICK
INITIAL STARTUP
CENTER JOYSTICK
JOYSTICK IS FORWARD
CENTER JOYSTICK
JOYSTICK IS BACK
CENTER JOYSTICK
TOO FAST FOR GRADE
CHARGE BATTERIES
BATTERY VOLTS LOW
INCLINE TOO STEEP
MOTOR STALLED
CYCLE FOOT SWITCH
TO DRIVE
