Page 8 Operator Manual
067449-023 LX31/LX41 Electric and BiEnergy Operation
O
PERATION
NOTE: Before operating the work platform, ensure that the pre-operation and safety inspection has been completed,
any deficiencies have been corrected, and the operator has been thoroughly trained on this machine.
W A R N I N G ! !
Never operate the work platform with the parking brakes released. Serious injury or damage could
result.
T R A V E L W I T H P L A T F O R M L O W E R E D
1. Verify the following:
• the chassis Emergency Stop button is in the ON position (pull out)
• the Drive Enable indicator is ON
• the Platform/Chassis switch is on PLATFORM.
NOTE: If the drive enable indicator is OFF, verify that the platform is fully lowered and (if so equipped) the outriggers
are fully retracted.
2. After mounting the platform, close and latch the gate. Check that the guardrails are in position and
properly assembled, with the fasteners properly torqued.
3. Check that the route is clear of persons, obstructions, holes and drop-offs, and is capable of supporting
the wheel loads.
4. Check clearances above, below and to the sides of the platform.
5. Pull the controller Emergency Stop button out to the ON position.
6. Turn the Platform Controls key switch clockwise to ON.
A. BiEnergy may be powered by batteries or engine. To power by engine:
a. Set the Chassis Controls key switch to RUN.
b. Start from Chassis Controls
• Press the START button to start the engine, releasing the button once the engine starts.
c. Start from Platform Controls
• Turn the key fully clockwise to start the engine, releasing the key once the engine starts.
NOTE: If the engine is cold, depress the glow plug button and hold for 6 seconds to heat the glow plugs.
7. Set the Lift/Drive switch to DRIVE.
8. Set the speed range switch to HIGH TORQUE.
9. Grasp the control lever so that the interlock lever switch is depressed (releasing the interlock lever
switch cuts power to controller). Slowly push or pull the control lever to FORWARD or REVERSE to
travel in the desired direction. The farther you push or pull the control lever from center, the faster the
machine will travel.
10. While moving, push the speed range switch to HIGH SPEED for travel on level surfaces or to HIGH
TORQUE for climbing grades or traveling in confined areas.
