AEM Infinity Supported Applications - Ford Coyote Engine with Ford Racing Control Pack User Manual
Page 32

32
© 2014 AEM Performance Electronics
Infinity
Pin
Infinity Assignment
Pin
Destination
Ford Coyote with FR
Control Pack
Description
Infinity Hardware
Specification
Notes
C2-18
Analog_In_13
---
Oil Pressure
12 bit A/D, 100K pullup to
5V
0–5V analog signal. Use +5V Out
pins as power supply and Sensor
Ground pins as the low ref erence.
Do not connect signals ref erenced
to +12V as this can permanently
damage the ECU. See Setup
Wizard 'Oil Pressure' page f or
setup options. See OilPressure
[psig] f or channel data.
C2-19
Analog_In_14
---
Traction Control Mode /
Sensitiv ity
12 bit A/D, 100K pullup to
5V
0–5V analog signal. Use +5V Out
pins as power supply and Sensor
Ground pins as the low ref erence.
Do not connect signals ref erenced
to +12V as this can permanently
damage the ECU. See the
TC_SlipTrgtTrim [MPH] 1-axis
table. A multi-position rotary switch
such as AEM P/N 30-2056 is
recommended.
C2-20
Analog_In_15
---
Exhaust Back Pressure
12 bit A/D, 100K pullup to
5V
0–5V analog signal. Use +5V Out
pins as power supply and Sensor
Ground pins as the low ref erence.
Do not connect signals ref erenced
to +12V as this can permanently
damage the ECU. See Setup
Wizard 'Exhaust Pressure' page f or
setup options. See EBPress [kPa]
f or channel data.
C2-21
Analog_In_16
Engine
E-10
Throttle Position #
Positiv e Slope (TP2)
12 bit A/D, 100K pullup to
5V
0–5V analog signal. Use +5V Out
pins as power supply and Sensor
Ground pins as the low ref erence.
Do not connect signals ref erenced
to +12V as this can permanently
damage the ECU.
C2-22
+5V_Out_2
Ford Racing
PCM70-45
APPVREF (1)
Regulated, f used +5V
supply f or sensor power
Analog sensor power
C2-23
+5V_Out_2
Ford Racing
PCM70-61
APPVREF (2)
Regulated, f used +5V
supply f or sensor power
Analog sensor power
C2-24
+5V_Out_2
---
+5V Out
Regulated, f used +5V
supply f or sensor power
Analog sensor power
C2-25
VR+_In_5
---
Driv en Right Wheel
Speed Sensor +
Dif f erential Variable
Reluctance Zero Cross
Detection
See Driv en Wheel Speed
Calibration in the Setup Wizard
'Input Function Assignment' page.
C2-26
VR-_In_5
---
Driv en Right Wheel
Speed Sensor -
C2-27
VR-_In_4
---
Non Driv en Right Wheel
Speed Sensor -
Dif f erential Variable
Reluctance Zero Cross
Detection
See Non Driv en Wheel Speed
Calibration in the Setup Wizard
'Input Function Assignment' page.
C2-28
V R+_In_4
---
Non Driv en Right Wheel
Speed Sensor +
