Infinity Supported Application 31
© 2014 AEM Performance Electronics
Infinity
Pin
Infinity Assignment
Pin
Destination
Ford Coyote with FR
Control Pack
Description
Infinity Hardware
Specification
Notes
C2-7 Injector 10 --- Injector 10
Saturated or peak and
hold, 3A max continuous
Injector 10
C2-8 Power Ground
Ford Racing
PCM70-50
Case Ground Power Ground Connect directly to battery ground.
C2-9 +12V
Ford
Racing
PCM70-68
VPWR 12 v olt power f rom relay
12 v olt power f rom relay . Relay
must be controlled by +12V Relay
Control signal, pin C1-29 abov e.
C2-10 Injector 11 --- Injector 11
Saturated or peak and
hold, 3A max continuous
Not used
C2-11 Injector 12 --- Injector 12
Saturated or peak and
hold, 3A max continuous
Not used
C2-12 Analog_In_17 --- A/C Analog Request
12 bit A/D, 100K pullup to
5V
0–5V analog signal. Use +5V Out
pins as power supply and Sensor
Ground pins as the low ref erence.
Do not connect signals ref erenced
to +12V as this can permanently
damage the ECU. See Setup
Wizard 'Input Functions' page f or
input selection. See
AC_Request_In 1-axis table f or
activ ation logic.
C2-13 Analog_In_18
Ford Racing
PCM70-28
DBW_APP1 [%]
12 bit A/D, 100K pullup to
5V
0–5V analog signal. Use +5V Out
pins as power supply and Sensor
Ground pins as the low ref erence.
Do not connect signals ref erenced
to +12V as this can permanently
damage the ECU.
C2-14 Analog_In_19
Ford Racing
PCM70-29
DBW_APP2 [%]
12 bit A/D, 100K pullup to
5V
0–5V analog signal. Use +5V Out
pins as power supply and Sensor
Ground pins as the low ref erence.
Do not connect signals ref erenced
to +12V as this can permanently
damage the ECU.
C2-15 Analog_In_Temp_4 --- Charge Out Temperature
12 bit A/D, 2.49K pullup
to 5V
See ChargeOutTemp [C] table f or
calibration data and
ChargeOutTemp [C] f or channel
data.
C2-16 Analog_In_Temp_5 --- Airbox Temperature
12 bit A/D, 2.49K pullup
to 5V
See AirboxTemp [C] table f or
calibration data and AirboxTemp
[C] f or channel data.
C2-17 Analog_In_Temp_6 --- Fuel Temperature
12 bit A/D, 2.49K pullup
to 5V
See FuelTemp [C] table f or
calibration data and FuelTemp [C]
f or channel data.
