Infinity Supported Application
17
© 2014 AEM Performance Electronics
Ford
Racing
PCM70
Pin
Wire Color
Ford Coyote
with FR
Control Pack
Description
Infinity
Pin
Infinity
Assignment
Infinity Hardware
Specification
Notes
PCM70-07
Light Green/Y ellow
Starter Motor
Control (SMC)
C2-43
LowsideSwitch_8
Lowside switch, 4A
max with internal
f ly back diode.
Inductiv e load should
NOT hav e f ull time
power.
See Setup Wizard
Page ‘LowSide
Assignment Tables’
f or conf iguration
options. See 2D table
‘LS8_Duty [%]’ f or
activ ation settings.
PCM70-08
---
---
---
Not used
---
Not used
Not used
Not used
PCM70-09
---
---
---
Not used
---
Not used
Not used
Not used
PCM70-10
Tan/Y ellow
Tacho (CTO)
Blunt Lead
C2-29
LowsideSwitch_9
Lowside switch, 4A
max with internal
f ly back diode, 2.2K
12V pullup. Inductiv e
load should NOT
hav e f ull time power.
See Setup Wizard
page 'Tacho' f or
conf iguration options.
PCM70-11
---
---
---
Not used
---
Not used
Not used
Not used
PCM70-12
---
---
---
Not used
---
Not used
Not used
Not used
PCM70-13
---
---
---
Not used
---
Not used
Not used
Not used
PCM70-14
---
---
---
Not used
---
Not used
Not used
Not used
PCM70-15
---
---
---
Not used
---
Not used
Not used
Not used
PCM70-16
---
---
---
Not used
---
Not used
Not used
Not used
PCM70-17
---
---
---
Not used
---
Not used
Not used
Not used
PCM70-18
Tan/Red
Fan Relay
Control
C1-17
LowsideSwitch_2
Lowside switch, 4A
max, NO internal
f ly back diode.
See Setup Wizard
Page ‘LowSide
Assignment Tables’
f or conf iguration
options. See 2D table
‘LS5_Duty [%]’ f or
activ ation settings.
See Setup Wizard
page 'User GPOs' f or
def ault activ ation
criteria.
PCM70-19
---
---
---
Not used
---
Not used
Not used
Not used
PCM70-20
---
---
---
Not used
---
Not used
Not used
Not used
PCM70-21*
Blue
Injector and
Digital Cam
Sensor +12V
Power – Shared
with E-36
C1-61
+12V
12 v olt power f rom
relay
12 v olt power f rom
relay . Relay must be
controlled by +12V
Relay Control signal,
pin C1-29 abov e.
PCM70-22
---
---
---
Not used
---
Not used
Not used
Not used
PCM70-23
---
---
---
Not used
---
Not used
Not used
Not used
PCM70-24
---
---
---
Not used
---
Not used
Not used
Not used
PCM70-25
---
---
---
Not used
---
Not used
Not used
Not used
