Infinity Supported Application
15
© 2014 AEM Performance Electronics
Ford
Engine
Pin
Wire Color
Ford Coyote
with FR
Control Pack
Description
Infinity
Pin
Infinity
Assignment
Infinity Hardware
Specification
Notes
E-52
Y ellow/Blue
Coil on Plug
Assembly 2
(COP2H)
C1-13
Coil 2
25 mA max source
current
0–5V Falling edge
f ire. DO NOT
connect directly to
coil primary . Must
use an ignitor OR
CDI that accepts a
FALLING edge f ire
signal.
E-53
Green/Blue
Fuel Injector
Driv er 1 (INJ1)
C1-63
Injector 1
Saturated or peak
and hold, 3A max
continuous
Injector 1
E-54
Grey /Y ellow
Fuel Injector
Driv er 2 (INJ2)
C1-62
Injector 2
Saturated or peak
and hold, 3A max
continuous
Injector 2
E-55
Violet/Grey
Fuel Injector
Driv er 3 (INJ3)
C1-59
Injector 3
Saturated or peak
and hold, 3A max
continuous
Injector 3
E-56
White/Orange
Variable
Camshaf t
Timing 12
Solenoid
(Passengerside
Exhaust)
C1-3
LowsideSwitch_6
Lowside switch, 4A
max with internal
f ly back diode.
Inductiv e load should
NOT hav e f ull time
power.
See Setup Wizard
Page ‘LowSide
Assignment Tables’
f or conf iguration
options. See 2D table
‘LS6_Duty [%]’ f or
activ ation settings.
See Setup Wizard
page 'VVC' f or
options.
E-57
Brown/Violet
Variable
Camshaf t
Timing 22
Solenoid
(Driv erside
Exhaust)
C2-44
LowsideSwitch_7
Lowside switch, 4A
max with internal
f ly back diode.
Inductiv e load should
NOT hav e f ull time
power.
See Setup Wizard
Page ‘LowSide
Assignment Tables’
f or conf iguration
options. See 2D table
‘LS7_Duty [%]’ f or
activ ation settings.
See Setup Wizard
page 'VVC' f or
options.
E-58
---
---
---
Not used
---
Not used
Not used
Not used
E-59
---
---
---
Not used
---
Not used
Not used
Not used
E-60
---
---
---
Not used
---
Not used
Not used
Not used
E-61
---
---
---
Not used
---
Not used
Not used
Not used
E-62
Y ellow/Orange
Fuel Injector
Driv er 4 (INJ4)
C1-58
Injector 4
Saturated or peak
and hold, 3A max
continuous
Injector 4
E-63
Brown
Fuel Injector
Driv er 5 (INJ5)
C1-57
Injector 5
Saturated or peak
and hold, 3A max
continuous
Injector 5
E-64
Green/White
Fuel Injector
Driv er 6 (INJ6)
C1-56
Injector 6
Saturated or peak
and hold, 3A max
continuous
Injector 6
