AEM Infinity Supported Applications - Ford Coyote Engine with Ford Racing Control Pack User Manual
Page 22

22
© 2014 AEM Performance Electronics
Ford
Racing
PCM50
Pin
Wire Color
Ford Coyote
with FR
Control Pack
Description
Infinity
Pin
Infinity
Assignment
Infinity Hardware
Specification
Notes
PCM50-23
---
---
---
Not used
---
Not used
Not used
Not used
PCM50-24
Red/White
HTR Bank 1
C1-4
UEGO 1 Heat
Bosch UEGO
controller
Lowside switch f or
UEGO heater control.
Connect to pin 4 of
Bosch UEGO sensor.
NOTE that pin 3 of
the Sensor is heater
(+) and must be
power by a f used/
switched 12V supply .
PCM50-25
---
---
---
Not used
---
Not used
Not used
Not used
PCM50-26
---
---
---
Not used
---
Not used
Not used
Not used
PCM50-27
---
---
---
Not used
---
Not used
Not used
Not used
PCM50-28
White
UO2SIA Bank 2
C2-48
UEGO 2 IA
Bosch UEGO
controller
Trim Current signal.
Connect to pin 2 of
Bosch UEGO sensor.
PCM50-29
Brown/y ellow
U02SIA Bank 1
C1-5
UEGO 1 IA
Bosch UEGO
controller
Trim Current signal.
Connect to pin 2 of
Bosch UEGO sensor.
PCM50-30
---
---
---
Not used
---
Not used
Not used
Not used
PCM50-31
---
---
---
Not used
---
Not used
Not used
Not used
PCM50-32
---
---
---
Not used
---
Not used
Not used
Not used
PCM50-33
---
---
---
Not used
---
Not used
Not used
Not used
PCM50-34
---
---
---
Not used
---
Not used
Not used
Not used
PCM50-35
Red/Black
HTR Bank 2
C2-49
UEGO 2 HEAT
Bosch UEGO
controller
Lowside switch f or
UEGO heater control.
Connect to pin 4 of
Bosch UEGO sensor.
NOTE that pin 3 of
the Sensor is heater
(+) and must be
power by a f used/
switched 12V supply .
PCM50-36
---
---
---
Not used
---
Not used
Not used
Not used
PCM50-37
---
---
---
Not used
---
Not used
Not used
Not used
PCM50-38
---
---
---
Not used
---
Not used
Not used
Not used
PCM50-39
Green/White
UO2SN Bank 2
C2-46
UEGO 2 UN
Bosch UEGO
controller
Nernst Voltage
signal. Connect to pin
1 of Bosch UEGO
sensor.
PCM50-40
Violet
UREF Bank 2
C2-45
UEGO 2 VM
Bosch UEGO
controller
Virtual Ground signal.
Connect to pin 5 of
Bosch UEGO sensor.
PCM50-41
---
---
---
Not used
---
Not used
Not used
Not used
