3805 kit contents, Ecu connectors, 4ecu connectors – AEM 30-3805 Universal V8 Core Harness User Manual
Page 4
AEM Infinity Harness Manuals
4
© 2014 AEM Performance Electronics
Extension harness to connect AEM UEGO Wideband O2 sensor to 6 pin Deutsch DTM
in Infinity Mini Harnesses (30-3702/3703).
30-3601 IP67 Comms Cable
USB Mini-B comms cable; 39” long with right angled connector and bayonet style lock.
30-3602 IP67 Logging Cable
USB A-to-A extension cable: 39” long with right angled connector and bayonet style
lock.
3
3805 Kit Contents
Universal V8 Core Harness
User Instructions
DTM 8 Way Receptacle Assembly with 8 contacts
DTM 8 Way Plug Assembly with 8 contacts
4
ECU Connectors
The Infinity-6/8h/8/10 ECUs use the MX123 Sealed Connection System from Molex.
AEM strongly recommends that users become familiar with the proper tools and
procedures before attempting any modifications or additions to these connector
