AEM 30-3805 Universal V8 Core Harness User Manual

Page 27

Infinity Pin

Hrdwr Ref.

Hardware Specification

Notes

C1-37

Analog_In_9

12 bit A/D, 100K pullup to 5V

0-5V analog signal. Use +5V Out pins as power
supply and Sensor Ground pins as the low
reference. Do not connect signals referenced to
+12V as this can permanently damage the ECU.
See the Setup Wizard Fuel Pressure page for setup
and calibration.

C1-38

Analog_In_10

12 bit A/D, 100K pullup to 5V

C1-39

Analog_In_11

12 bit A/D, 100K pullup to 5V

0-5V analog signal. Use +5V Out pins as power
supply and Sensor Ground pins as the low
reference. Do not connect signals referenced to
+12V as this can permanently damage the ECU.
Normally used as Shift Switch input.

C1-40

Analog_In_12

12 bit A/D, 100K pullup to 5V

C1-41

+5V_Out_1

Regulated, fused +5V supply for
sensor power

Analog sensor power

C1-42

+5V_Out_1

Regulated, fused +5V supply for
sensor power

Analog sensor power

C1-43

HighsideSwitch_1

0.7A max, High Side Solid State
Relay

See Setup Wizard page 'HighSide Assigment
Tables' for configuration options.

C1-44

HighsideSwitch_0

0.7A max, High Side Solid State
Relay

See Setup Wizard page 'HighSide Assigment
Tables' for configuration options.

C1-45

Crankshaft Position
Sensor VR+

Differential Variable Reluctance
Zero Cross Detection

See Setup Wizard page Cam/Crank for options.

C1-46

Crankshaft Position
Sensor VR-

See Setup Wizard page Cam/Crank for options.

C1-47

Camshaft Position
Sensor 1 VR-

Differential Variable Reluctance
Zero Cross Detection

See Setup Wizard page Cam/Crank for options.

C1-48

Camshaft Position
Sensor 1 VR+

See Setup Wizard page Cam/Crank for options.
