AEM 30-3805 Universal V8 Core Harness - Manual (Page 11)

11
© 2014 AEM Performance Electronics
C1-27 ---
C1-28 ---
C1-29 YEL/WHT 20 P1-1 +12V_Relay_Cntrl (Lowside switch output)
C1-30 BLK 20 S1 Battery Ground
C1-31 GRN 20 C4-2 AEMNet CANL
C1-32 WHT 20 C4-1 AEMNet CANH
C1-33 WHT/RED 20 C8-4 LowsideSwitch_1 (Boost Control Soleonoid)
C1-34 VIO/WHT 20 P1-13 LowsideSwitch_0 (Fuel Pump)
C1-35 DK BLU 20 F2 Analog_In_7 (Throttle Position Sensor)
C1-36 LT GRN 20 F1 Analog_In_8 (MAP Sensor)
C1-37 GRN/BLU 20 F3 Analog_In_9 (Fuel Pressure Sensor)
C1-38 BLU/BRN 20 C8-7 Analog_In_10 (Baro Sensor)
C1-39 BRN/ORG 20 C8-5 Analog_In_11 (Shift Switch Input)
C1-40 LT GRN 20 C8-6 Analog_In_12 (Mode Switch)
C1-41 GRY 20 S3 +5V_Out_1 (Analog Sensor Power)
C1-42 ORG 20 C10-5 +5V_Out_1 (Analog Sensor Power)
C1-43 ---
C1-44 ---
C1-45 BLK 22 C10-7 Crank Position (VR+)
C1-46 RED 22 C10-8 Crank Position (VR-)
C1-47 WHT 22 C10-9 Cam1 Position (VR-)
C1-48 GRN 22 C10-10 Cam1 Position (VR+)
C1-49 ---
C1-50 ---
C1-51 ---
C1-52 ---
C1-53 ---
C1-54 ---
C1-55 BLK 20 S7 Battery Ground
C1-56 YEL/BLK 20 C6-10 Injector 6
C1-57 BLU/RED 20 C6-9 Injector 5
C1-58 LT BLU/BLK 20 C6-4 Injector 4
C1-59 PNK/BLK 20 C6-3 Injector 3
C1-60 BLK 20 C16-L Battery Ground
C1-61 RED 20 C3-G Fused +12V Power from Relay
C1-62 LT GRN/BLK 20 C6-2 Injector 2
C1-63 BLU 20 C6-1 Injector 1
