1 LT GRN/WHT 20 C1-69 Stepper_2A
2 LT BLU/WHT 20 C1-70 Stepper_1A
3 LT GRN/BLK 20 C1-71 Stepper_2B
4 LT BLU/BLK 20 C1-72 Stepper_1B
5 ORG/RED 20 C1-3 LowsideSwitch_6 (PWM Idle)
6 RED 20 C3-F Fused +12V Relay Power
C12
DTM Receptacle, 6 Way
Pin Wire Color Gauge
Destination
UEGO2
1 2 3
1 BLK 20 C2-46 UEGO2_UN
2 GRN 20 C2-48 UEGO2_IA
3 BRN 20 C3-K Fused +12V Relay Power
4 WHT 18 C2-49 UEGO_2_Heat
5 ORG 20 C2-45 UEGO2_VM
6 RED 20 C2-47 UEGO2_IP
C13
DTM Receptacle, 6 Way
Pin Wire Color Gauge
Destination
UEGO1
1 2 3
1 BLK 20 C1-7 UEGO1_UN
2 GRN 20 C1-5 UEGO1_IA
3 BRN 20 C3-K Fused +12V Relay Power
4 WHT 18 C1-4 UEGO1_Heat
5 ORN 20 C1-8 UEGO1_VM
6 RED 20 C1-6 UEGO1_IP
C14
DTM Receptacle, 2 Way
Pin Wire Color Gauge
Destination
Flash
1 2 3
1 RED 20 P1-8 Fused +12V Battery Power
2 RED 20 C1-9 Flash_Enable
C15
280 METRI-PACK 12F
Pin Wire Color Gauge Destination
