5 ORG/WHT 20 C1-39 Analog_In_11 (Shift Switch Input)
6 RED/GRN 20 C1-40 Analog_In_12 (Mode Switch)
7 BLU/BRN 20 C1-38 Analog_In_10 (Baro Sensor)
8 BLK/RED 20 C1-26 Digital_In_5 (Flex Fuel Sensor)
C9
DTM Receptacle, 8 Way
Pin Wire Color Gauge
Destination
Aux1
1 2 3
1 ORG/WHT 20 C2-29 LowsideSwitch_9 (Tachometer Output)
2 LT GRN 20 C2-43 LowsideSwitch_8 (Engine Protect Warning Output)
3 DK BLU/RED 20 C2-19 Analog_In_14
4 ORG/GRN 20 C2-12 Analog_In_17 (A/C Request)
5 RED/BLK 20 C2-34 Analog_In_21 (3 Step Enable)
6 BLK/WHT 20 C2-38 Digital_In_7 (Clutch Switch)
7 GRY 20 C2-22 +5V_Out_2 (Analog Sensor Power)
8 BLK/WHT 20 C2-31 AGND_2 (Sensor Ground)
C10
DTM Receptacle, 12 Way
Pin Wire Color Gauge
Destination
Crank/Cam
1 2 3
1 WHITE 22 C1-21 Crank Position Sensor (Hall Effect)
2 BLK 22 C1-20 AGND_1 (Analog Sensor Ground)
3 GRN 22 C1-22 Camshaft Position Sensor 1 (Hall Effect)
4 RED 22 S6 Fused +12V Relay Power
5 ORG 22 C1-42 +5V_Out_1 (Analog Sensor Power)
6
7 BLK 22 C1-45 Crank Position (VR+)
8 RED 22 C1-46 Crank Position (VR-)
9 WHT 22 C1-47 Cam1 Position (VR-)
10 GRN 22 C1-48 Cam1 Position (VR+)
11 BLK 22 S7 Shield Ground
12
C11
DTM Receptacle, 6 Way
Pin Wire Color Gauge
Destination
Idle
1 2 3
