AEM 30-3805 Universal V8 Core Harness - Manual (Page 32)

AEM Infinity Harness Manuals 32
© 2014 AEM Performance Electronics
Infinity Pin Hrdwr Ref. Hardware Specification Notes
C2-33 Analog_In_20 12 bit A/D, 100K pullup to 5V 0-5V analog signal. Use +5V Out pins as power
supply and Sensor Ground pins as the low
reference. Do not connect signals referenced to
+12V as this can permanently damage the ECU.
C2-34 Analog_In_21 12 bit A/D, 100K pullup to 5V 0-5V analog signal. Use +5V Out pins as power
supply and Sensor Ground pins as the low
reference. Do not connect signals referenced to
+12V as this can permanently damage the ECU.
Normally used as 3 Step Enable Switch input.
C2-35 Analog_In_22 12 bit A/D, 100K pullup to 5V 0-5V analog signal. Use +5V Out pins as power
supply and Sensor Ground pins as the low
reference. Do not connect signals referenced to
+12V as this can permanently damage the ECU.
Normally used as USB Logging Request input.
C2-36 Analog_In_23 12 bit A/D, 100K pullup to 5V 0-5V analog signal. Use +5V Out pins as power
supply and Sensor Ground pins as the low
reference. Do not connect signals referenced to
+12V as this can permanently damage the ECU.
Normally used as Charge Out Pressure input.
C2-37 Digital_In_6 No pullup. Will work with TTL
signals. Input can be assigned to different pins. See Setup
Wizard page Input Function Assignments for input
mapping options.
C2-38 Digital_In_7 No pullup. Will work with TTL
signals. See ClutchSwitch 1-axis table for setup options.
Input can be assigned to different pins. See Setup
Wizard page Input Function Assignments for input
mapping options.
C2-39 Power Ground Power Ground Connect directly to battery ground
C2-40 Power Ground Power Ground Connect directly to battery ground
C2-41 CanH_Bout Dedicated High Speed CAN
Transceiver Not used
C2-42 CanL_Bout Dedicated High Speed CAN
Transceiver Not used
