4 RED 20 R4 +12V Battery Power
5
6
7 RED 12 C16-C +12V Battery Power
8 RED 20, 20, 20 C1-10 C2-50
C14-
1 Fused +12V Battery Power
9 RED 12 P1-3 Fused +12V Battery Power
10 RED 22 P1-3 Fused +12V Battery Power
11 RED 12 P1-33 Fused +12V Battery Power
12 RED 12 P1-21 Fused +12V Battery Power
13 VIO/WHT 20 C1-34 LowsideSwitch_0 (Fuel Pump)
14 RED/GRN 12 F7 Fused +12V Power for Fuel Pump
15 RED 12 C16-D +12V Battery Power
16 RED 12 C16-F +12V Battery Power
17
18
19 RED 12 P1-47 Fused +12V Battery Power
20 RED 12 P1-45 Fused +12V Battery Power
21 RED 12 P1-12 Fused +12V Battery Power
22 RED 20 C3-B Fused +12V Battery Power
23 RED 12 C16-E +12V Battery Power
24 RED 12 R3 +12V Battery Power
25 BLACK 20 C16-K Battery Ground
26 RED 12 C15-G Fused +12V Battery Power for Inj. And Coils
27 PNK/WHT 20 C1-65 Fused +12V Switched Ignition Power
28
29
30
31 PNK/WHT 22 F7 +12V Switched Ignition Power
32
33 RED 12 P1-11 Fused +12V Battery Power
34 RED 20 C3-C Fused +12V Battery Power
35
36
37 VIO 20 C1-17 LowsideSwitch_2 (Coolant Fan 1 Control)
38 RED/BLU 12 F7 Fused +12V Power for Coolant Fan 1
39 BLK 22 C16-J Battery Ground
