AEM 30-3805 Universal V8 Core Harness - Manual (Page 14)

AEM Infinity Harness Manuals 14
© 2014 AEM Performance Electronics
Pin Wire Color Gauge
Destination
1 2 3
A RED 12 P1-2 Fused +12V Relay Power
B RED 20 P1-22 Fused +12V Relay Power
C RED 20 P1-34 Fused +12V Relay Power
D RED 20 P1-46 Fused +12V Relay Power
E RED 20 P1-48 Fused +12V Relay Power
F RED 20 C11-6 Fused +12V Relay Power
G RED 20 C1-61 Fused +12V Relay Power
H RED 20 F7 Fused +12V Relay Power
J RED 22 S6 Fused +12V Relay Power
K BRN 20 C12-3 C13-3 Fused +12V Relay Power
L RED 20 C1-64 Fused +12V Relay Power
M RED 20 C2-9 Fused +12V Relay Power
C4
DTM Plug, 4 Way
Pin Wire Color Gauge
Destination
AEMNet
1 2 3
1 WHT 20 C1-32 AEMNet CANH
2 GRN 20 C1-31 AEMNet CANL
3 RED 22 S6 Power Splice
4 BLK 22 S1 Ground Splice
C5
DT Plug, 12 Way
Pin Wire Color Gauge
Destination
Coils
1 2 3
1 VIO 20 C1-14 Coil1
2 RED/WHT 20 C1-13 Coil2
3 LT BLU 20 C1-12 Coil3
4 DK GRN/WHT 20 C1-11 Coil4
5 BLK/WHT 20 C2-30 AGND_2 (Sensor Ground)
6 RED 14 C15-D Fused +12V Relay Power
7 RED 14 C15-K Fused +12V Relay Power
8 BLK 14 C16-M Battery Ground
9 DK GRN 20 C1-16 Coil5
10 LT BLU/WHT 20 C1-15 Coil6
