AEM 30-3805 Universal V8 Core Harness - Manual (Page 20)

AEM Infinity Harness Manuals 20
© 2014 AEM Performance Electronics
40 RED 12 C15-A Fused +12V Battery Power for Inj. And Coils
41
42
43
44
45 RED 12 P1-20 Fused +12V Battery Power
46 RED 20 C3-D Fused +12V Relay Power
47 RED 12 P1-19 Fused +12V Battery Power
48 RED 20 C3-E Fused +12V Relay Power
F1
Flying Leads
Pin Wire Color Gauge
Destination
MAP
1 2 3
LT GRN 20 C1-36 Analog_In_8 (MAP Sensor)
BLK/WHT 22 S2 AGND_1 (Analog Sensor Ground)
GRY 22 S3 +5V_Out_1 (Analog Sensor Power)
F2
Flying Leads
Pin Wire Color Gauge
Destination
Throttle
1 2 3
DK BLU 20 C1-35 Analog_In_7 (Throttle Position Sensor)
BLK/WHT 22 S2 AGND_1 (Analog Sensor Ground)
GRY 22 S3 +5V_Out_1 (Analog Sensor Power)
F3
Flying Leads
Pin Wire Color Gauge
Destination
FuelPress
1 2 3
GRN/BLU 20 C1-37 Analog_In_9 (Fuel Pressure Sensor)
BLK/WHT 22 S2 AGND_1 (Analog Sensor Ground)
GRY 20 C2-24 +5V_Out_2 (Analog Sensor Power)
F4
Flying Leads
Pin Wire Color Gauge
Destination
OilPress
1 2 3
GRN 20 C2-18 Analog_In_13 (Oil Pressure)
