C2-23 GRY 20 F4 +5V_Out_2 (Analog Sensor Power)
C2-24 GRY 20 F3 +5V_Out_2 (Analog Sensor Power)
C2-25 WHT 22 C7-1 VR+_In_5 (Driven Rt Wheel VR+)
C2-26 BLK 22 C7-2 VR-_In_5 (Driven Rt Wheel VR-)
C2-27 WHT 22 C7-4 VR-_In_4 (Non Driven Rt Wheel VR-)
C2-28 BLK 22 C7-5 VR+_In_4 (Non Driven Rt Wheel VR+)
C2-29 ORG/WHT 20 C9-1 LowsideSwitch_9 (Tachometer Output)
C2-30 BLK/WHT 20 C5-5 AGND_2 (Analog Sensor Ground)
C2-31 BLK/WHT 20 C9-8 AGND_2 (Analog Sensor Ground)
C2-32 BLK/WHT 20 S4 AGND_2 (Analog Sensor Ground)
C2-33 ---
C2-34 RED/BLK 20 C9-5 Analog_In_21 (3 Step Enable)
C2-35
C2-36
C2-37
C2-38 BLK/WHT 20 C9-6 Digital_In_7 (Clutch Switch)
C2-39 BLK 20 S5 Battery Ground
C2-40 BLK 20 C16-J Battery Ground
C2-41 ---
C2-42 ---
C2-43 RED/GRN 20 C9-2 LowsideSwitch_8 (Engine Protect Warning Output)
C2-44 ---
C2-45 ORG 20 C12-5 UEGO2_VM
C2-46 BLK 20 C12-1 UEGO2_UN
C2-47 RED 20 C12-6 UEGO2_IP
C2-48 GRN 20 C12-2 UEGO2_IA
C2-49 WHT 18 C12-4 UEGO_2_Heat
C2-50 RED 20 P1-8 Fused +12V_R8C_CPU (Perm Power)
C2-51 TAN 20 C5-11 Coil 7
C2-52 VIO/WHT 20 C5-12 Coil 8
C2-53 ---
C2-54 ---
C2-55 ---
C2-56 ---
C3
280 METRI-PACK 12F
