9-1
Service Mode
5975398 BARCODATA 3200 110797
Select with or
then
9
SERVICE MODE
Starting up the Service Mode
Push the control disk up or up to highlight Service and then press
ENTER.
Some items in the Service mode are password protected (when the
password function is active). Enter your password to continue. All
other password protected items are now available if you stay in the
adjustment mode.
The service menu is built-up in two parts which are connected
together with the 'more' item.
If the disered item is not in the list of the displayed menu, select more
with the control disk and push ENTER to display the other items in the
service menu.
ENTER continues to the Service mode selection menu.
EXIT returns to operational mode.
ADJUSTMENT MODE
Select a path from below :
RANDOM ACCESS
INSTALLATION
SERVICE
LAMP RUNTIME HISTORY
Serial No
Runtime
-----------------------------------------------------
>
0111121
600 h
0110031
750 h
0110010
745 h
-----------------------------------------------------
LAMP DRIVE MODE
NORMAL
TEMPORARY BOOST
Select with or
then
RESET LAMP RUN TIME
Enter the
serial number
of the new lamp
0000000
Select with or
Reprogram with or
or numeric keys
SERVICE
PANEL ADJUSTMENTS
PRESET INPUT BALANCE
I2C DIAGNOSIS
MORE...
Select with or
then
SERVICE
IDENTIFICATION
CHANGE PASSWORD
CHANGE LANGUAGE
RESET LAMP RUNTIME
LAMP RUNTINE HISTORY
LAMP DRIVE MODE
MORE...
Select with or
then
BARCO
DATA 3200
Proj. address : 001
Soft. version : 3.0
Config : front/
ceiling
Baudrate PC : 9600
text : ON
Serial no.: 1010200
Run time : 100 h
Select with or
then
CHANGE PASSWORD
Enter new password
0000
Select with or
then
CHANGE LANGUAGE
ENGLISH
Select with or
then
Select with or
then
SERVICE
PANEL ADJUSTMENTS
PRESET INPUT BALANCE
I2C DIAGNOSIS
MORE...
SERVICE
IDENTIFICATION
CHANGE PASSWORD
CHANGE LANGUAGE
RESET LAMP RUNTIME
LAMP RUNTINE HISTORY
LAMP DRIVE MODE
MORE...
Select with or
then
