7-8
Random Access Adjustment Mode
5975398 BARCODATA 3200 110797
Audio Tuning
Highlight Audio Tuning by pushing the control disk up or down and
press ENTER to select.
The Audio Tuning menu will be displayed. The following items are
available :
- Volume
- Balance
- Bass
- Treble
- Mute
- Lock
- Fade
Volume, Balance, Bass and Treble
When a sound control is selected by highlighting the item with the
control disk, a text box with a bar scale, icon and function name fo the
control, e.g. 'Volume' appears on the screen (only when text is ON).
The length of the bar scale indicates the current memory setting for
this source. For more information about the sound controls, see
'Sound controls with direct access' in the Chapter 'Controlling'.
Mute
Select 'Mute' to stop the sound reproduction.
Highlight 'Mute' with the control disk and press ENTER to toggle
between Mute [on] or Mute [off].
AUDIO TUNING
VOLUME
BALANCE
BASS
TREBLE
MUTE [OFF]
LOCK [INPUT 1]
FADE
Select with or
then
to return.
RANDOM ACCESS
ADJUSTMENT MODE
FILE SERVICE
PICTURE TUNING
AUDIO TUNING
GEOMETRY
Select with or
then
to return.
Lock [OFF/INPUT 1/INPUT 2/INPUT 3]
Select 'Lock' by pushing the control disk up or down and press ENTER
to toggle between OFF, INPUT 1, INPUT 2, INPUT 3.
Lock [OFF] : the sound corresponding to the selected input source will
be reproduced (see table in chapter 'Connections')
Lock [INPUT 1] : the sound corresponding to audio 1 input will be
reproduced independent the selected input source.
Lock [INPUT 2] : the sound corresponding to audio 2 input will be
reproduced independent the selected input source.
Lock [INPUT 3] : the sound corresponding to audio 3 input will be
reproduced independent the selected input source.
Fade
Select Fade by pushing the control disk up or down.
The fade can be adjusted between -15 and 15.
Fade on -15 : no sound reproduction on the external loudspeakers,
max on the internal loudspeaker with the same volume level as
adjusted with the volume control.
Fade on 15 : no sound reproduction on the internal loudspeakers but
max on the external loudspeakers with the same volume level as
adjusted with the volume control.
Select with or
then
to return.
AUDIO TUNING
VOLUME
BALANCE
BASS
TREBLE
MUTE [OFF]
LOCK [INPUT 1]
FADE
AUDIO TUNING
VOLUME
BALANCE
BASS
TREBLE
MUTE [OFF]
LOCK [INPUT 1]
FADE
AUDIO TUNING
VOLUME
BALANCE
BASS
TREBLE
MUTE [OFF]
LOCK [INPUT 1]
FADE
FADE
-15 0 15
