6-1
Start up of the Adjustment Mode
5975398 BARCODATA 3200 110797
6
START UP OF THE ADJUSTMENT MODE
Adjustment Mode
All source set ups, picture tunings and geometry are made while in the 'Adjustment mode'.
Press the ADJUST or ENTER key to enter the 'Adjustment mode'.
You are now in the 'Adjustment mode'. The control stick (RCU) or '+ or '-' keys (local keypad)
are used to make menu selections and also for adjustments. The ENTER and EXIT keys are
used to move forward and backward through the menu structure. The ADJUST key can
be used to terminate the adjustment mode while any path selection menu is displayed.
There are 3 possible paths to follow once in the Adjustment mode.
They are :
Installation - Installation should be selected if a new input module
is installed or a new source is connected to an existing input module.
Also when the projector is relocated in a new configuration.
Random Access - Random Access should be selected if the user
is used to set up a source.
Some items in the Adjustment mode are password protected. While selecting such an item,
the projector asks to enter your password (Password protection is only available when the
password strap on the controller module is ON, see 'Change password' in chapter 'Service
mode'.
Your password contains 4 digits.
Enter the digits with the numeric keys.
Example : 2 3 1 9
The first digit position is highlighted. Enter with the numeric keys. The highlighted square
jumps to the next position. Continue until all 4 digits are filled in.
When your password is correct, you get access to the selected item.
When your password is wrong. The error message "Invalid password" is displayed on the
screen. Press EXIT to continue and to return to the Service menu.
Factory programmed password : 0 0 0 0
Once the password is correctly entered, all other password protected items are accessible
without re-entering your password.
When re-entering the Adjustment mode, it will be nessary to enter your password again when
selecting a password protected item.
Service - Service should be selected if the user intends to change
general settings such as password, language, address, etc.or some
service actions as reset lamp run time, panel adjustments, etc. or get
set-up information.
ADJUSTMENT MODE
Select a path from below :
RANDOM ACCESS
INSTALLATION
SERVICE
Source 01
Select with or
then
ENTER PASSWORD
----
Use numeric keys
PASSWORD
Error
Invalid password
