8-1
Installation Mode
5975398 BARCODATA 3200 110797
Select with or
then
to return.
8
Internal Patterns
The projector is equipped with different internal patterns which can
be used for measurment purposes.
Highlight "Internal Patterns" by pushing the control disk up or down
and press ENTER to display the Internal Pattern selection menu.
The following test pattern are available :
- Color Bars
- Multiburst
- Checker Board
- Purity
- Page Char
- Alpha-numeric Char
Each pattern (except Purity) can be inverted by pressing ENTER.
To return to the normal pattern, press EXIT.
How to use the built-in adjustable lensholder.
With the lensholder, it is possible to shift the displayed image up or
down on the screen without moving the projector from its normal
position and without any geometric picture distortion. This built-in
feature is particularly useful for use in dual projector configurations
or for applications when the projector cannot be installed in its
standard position.
INSTALLATION MODE
Starting up the Installation Mode
Push the control disk up or down to highlight Installation and then
press ENTER.
ENTER continues to the Installation mode selection menu.
EXIT returns to operational mode.
The following item can be selected in the Installation mode :
Input slots : to set up the input for a specific source. See
'Connections' for the different source types.
Convergence : to adjust the convergence of the LCD panels. For
more information contact an authorised BARCO service technician.
Configuration : to set up the projector position.
Internal Patterns :
- color bars
- multiburst
- checker board
- purity
- Page Char
- Alpha-numeric Char
Configuration
Highlight "Configuration" by pushing the control disk up or down and
press ENTER to select.
For more information, see Projector configuration in chapter Instal-
lation Set Up.
ADJUSTMENT MODE
Select a path from below :
RANDOM ACCESS
INSTALLATION
SERVICE
Source 01
INSTALLATION
INPUT SLOTS
CONVERGENCE
CONFIGURATION
INTERNAL PATTERNS
Select with or
then
to return.
Select with or
then
to return.
INSTALLATION
INPUT SLOTS
CONVERGENCE
CONFIGURATION
INTERNAL PATTERNS
INSTALLATION
INPUT SLOTS
CONVERGENCE
CONFIGURATION
INTERNAL PATTERNS
INTERNAL PATTERNS
COLOR BARS
MULTIBURST
CHECKER BOARD
PURITY
PAGE CHAR
ALPHA-NUMERIC CHAR
Select with or
then
to return.
