Page 69: Gprs)

•

— Enter the login script. This setting is available only if you have selected

Use login script

Yes

•

Modem initialization

— Enter a command string for the connection setup, if required by your service provider.

Set up an Internet access point for packet data (GPRS)

1. Select

Settings

Config.

Connection

Access points

2. Select

Options

New access point

. To use an existing access point as a basis for the new one, select

Use existing settings

. To

start with an empty access point, select

Use default settings

3. Define the following settings.

•

Connection name

— Enter a descriptive name for the connection.

•

Data bearer

— Select

Packet data

•

Access point name

— Enter the name for the access point. The name is usually provided by your service provider or network

operator.

•

User name

— Enter your user name if required by the service provider. User names are often case-sensitive and provided

by your service provider.

•

Prompt password

— Select

Yes

to enter your password each time you log into a server or

to save the password in your

device memory and automate the login.

•

Password

— Enter your password if required by the service provider. The password is often case-sensitive provided by

the service provider.

•

Authentication

— Select

Secure

to always send your password encrypted or

Normal

to send your password encrypted

when possible.

•

Homepage

— Enter the Web address of the page you want to display as a home page when you use this access point.

4. After defining the settings, select

Options

Advanced config.

to define the advanced settings or

Back

to save the settings

and exit.

Advanced Internet access point settings for packet data (GPRS)

After setting up a basic Internet access point for packet data (GPRS), select

Options

Advanced config.

, and define the following

advanced settings:
•

Network type

— Select

IPv4

IPv6

as the Internet protocol type. The Internet protocol defines how data is transferred to

and from your device.

•

Phone IP address

— Enter the IP address of your device. Select

Automatic

to have the network provide the device IP address.

This setting is shown only if you select

Network type

IPv4

•

DNS address

— Enter the IP addresses of the

Primary DNS address

and

Secondary DNS addr.

if required by your service provider

or network operator. Otherwise, the name server addresses are provided automatically.

•

Proxy serv. address

— Enter the address of the proxy server. Proxy servers are intermediate servers between a browsing

service and its users, which are used by some service providers. These servers may provide additional security and speed up

access to the service.

Data connections

This device supports packet data (GPRS), high-speed data calls (HSCSD), and GSM data calls.

Packet data

GPRS (general packet radio service) enables wireless access for mobile phones to data networks (network service). GPRS uses

packet data technology where information is sent in short bursts of data over the mobile network. The benefit of sending data

in packets is that the network is occupied only when sending or receiving data. As GPRS uses the network efficiently, it allows

for quick data connection setup and fast data transmission speeds.
You must subscribe to the GPRS service. For availability and subscription to GPRS, contact your network operator or service

provider.
Enhanced GPRS (EGPRS) is similar to GPRS, but it enables faster connection. For more information on the availability of EGPRS

and data transfer speed, contact your network operator or service provider. Note that when you have selected GPRS as a data

bearer, the device uses EGPRS instead of GPRS if this is available in the network.
During a voice call, you cannot establish a GPRS connection, and any existing GPRS connection is put on hold unless the network

supports dual transfer mode.

High-speed data calls

HSCSD (high-speed circuit switched data) enables data transmission rates up to 43.2 kb/s, which is four times faster than standard

data rates of the GSM network. HSCSD is comparable to the speed of many computer modems that communicate with fixed

telephone networks.
For availability and subscription to high-speed data services, contact your network operator or service provider.

C o n n e c t i v i t y
