Using the dynadock™ and Adjusting Settings

Adjusting video settings

Mirror mode duplicates the image on your computer screen on the
external monitor(s) connected to the dynadock™. This mode is
useful if, for example, you want to view information on a larger,
external desktop monitor instead of a smaller, built-in computer
screen. In Mirror mode, the dynadock™ automatically adjusts the
external monitor’s resolution, color quality, and refresh rate settings
to provide the best overall image quality based on your computer’s
settings.

To configure the dynadock’s video output signal to Mirror mode or
Extended mode, connect an external monitor to the dynadock™ as
described in the section

“Connecting a monitor” on page 29

, and

then follow the steps below:

Right-click the TOSHIBA Video Dock icon in the System
tray/Notification Area of your Windows

desktop.

(Sample Image) TOSHIBA Video Dock icon

If the icon is not visible in your System tray/Notification Area, make
sure the dynadock™ is connected and docked, and then click the
Show Hidden Icons button [

], if necessary, to display hidden

icons.

Select Extend or Mirror from the menu.

If you notice certain windows or other parts of your display are
missing when you disconnect your computer from the dynadock™,
you may need to de-select the Extend my Windows

desktop onto

this monitor checkbox in your Windows

Display Properties dialog

box to return the entire image to your primary screen.

You can also use the Windows

Display Properties screen to switch

between Extended mode and Mirror mode.

The external monitor connected to the dynadock™ may be identified
as either "2" or “3” on the Windows

Display Properties screen

(depending on your computer model), even though there may not be
three viewable displays.
