47
Ch
ap
te
r
3
E
d
it
in
g t
h
e Na
viga
tio
n
Ut
il
it
ie
s
Selected picture is displayed at the centre of
the screen.
Repeat:
Selected picture is patterned, and displayed
as covering the whole screen.
❒
When selecting images already stored on
the Pioneer DVD map disc, you cannot
select the layout method for those images.
The background image starts changing. After
a short while, the new background image
appears.
7
Touch “Done”.
On this screen, you can select the following
items:
Select another Picture:
This is selected when you want to change to
another picture. Return to Step 5.
Change to another background:
Select if you want to successively change the
Audio Operating screen backgrounds or the
Navigation backgrounds. Return to Step 3.
❒ When changing a picture starts, do not cut off
the power supply for the navigation system (or
turn the ignition switch to ACC OFF) until the
message informing the completion of
changing a picture is indicated.
❒ When the Navigation System is reset, or the
language setting is changed, the background
picture may change back to the original
picture. (There is also a possibility that the
system will revert to the original picture for
some other reason.) If this happens, set the
background picture again.
Checking the Navigation Status
The navigation status, including the driving
status of a vehicle, positioning status by GPS
satellite, learning status of the 3D sensor, and
cable connection status can be checked.
Checking sensor learning status
and driving status
1
Touch “Information” in the Main menu,
then touch “3D Calibration Status”.
The 3D Calibration Status screen appears.
1. Distance
Driving distance is indicated.
2. Speed Pulse
Total number of speed pulses is indicated.
3. Learning Status
Current sensor status is indicated.
4. Degree of learning
Sensor learning situations of distance
(Distance), right turn (Right Turn), left
turn (Left Turn), and 3D detection (3D
Detection) are indicated by the length of
bars.
5. Speed
Speed detected by the navigation system is
indicated. (This indication may be different
from the actual speed of your vehicle, so
please do not use this instead of the
speedometer of your vehicle.)
6. Acceleration and deceleration/
Rotational speed
Accelerated or decelerated velocity of your
vehicle is indicated. Also, rotational speed
when your vehicle turns to left or right is
shown.
7. Inclination
Degree of slope of the street is indicated.
1
2
3
4
5 7 6
