How to view the map of the
current location
• In Driver’s View, a small gauge with no
scale is depicted, but is not intended to be
used as a speedometer. Use the actual
speedometer of your vehicle to confirm
speed.
Map Mode
Displays standard map.
Driver’s View
The map from the driver’s viewpoint is shown.
Mixed Mode
The map of your surroundings is shown on the
left, and an arrow indicating the direction of
travel is shown on the right.
St.List Mode
Displays the name of the street you will next
travel along and an arrow indicating the direction
of travel.
Enlarged map of the intersection
When “Close-up of Junction” in the Settings
menu is “On”, an enlarged map of the junction
appears. If driving on motorway, the special guide
illustration is displayed.
➲ Changing the close-up of junction setting
➞
Page 50
❒ When set to Driver’s View, the system
cannot be changed to an enlarged
intersection map.
When the city map is displayed, you cannot
switch to an enlarged map of the junction.
