9. Service mode
9. SERVICE MODE
9.1 Build-up
Build-up
The service menu is build-up in two parts which are connected together with the ’more’ item. If the desired item is not in the list of
the displayed menu, select ’more’ with the cursor key and push ENTER to display the other items in the service menu.
9.2 Start up
Start up
1. Push the cursor key
↑
or
↓
to highlight Service. (menu 9-1)
2. Press ENTER to display the service mode menu. (menu 9-2)
ADJUSTMENT MODE
Select a path from below :
AUTO IMAGE
RANDOM ACCESS
INSTALLATION
SERVICE
Source 01
Select with
↑
or
↓
then
to return.
Menu 9-1
SERVICE
IDENTIFICATION
CHANGE PASSWORD
CHANGE LANGUAGE
CHANGE PROJ. ADDRESS
CHANGE BAUDRATE PC
RESET LAMP RUNTIME
LAMP RUNTIME HISTORY
LAMP DIMMING
MORE...
Select with
↑
or
↓
then
to return.
Menu 9-2
SERVICE
BARCO LOGO
PANEL ADJUSTMENTS
UNIFORMITY
RESET INPUT BALANCE
I2C DIAGNOSIS
Select with
↑
or
↓
then
to return.
Menu 9-3
Some items in the Service mode are password protected (when the password function is active). Enter the
password to continue. All other password protected items are now available if you stay in the adjustment
mode.
9.3 Identification
What can be seen on the identification screen?
The identification screen shows the general information of the projector.
The following items will be displayed:
• Type of projector: BARCOREALITY SIM6
• Software version
• Network module: yes
• Proj. address: To change the address of the projector, see Box content, page 5
• Installation:
- front/ceiling
- front/table
- rear/ceiling
- rear/table
• Baud rate: transfer speed for communication with an IBM PC (or compatible) or MAC. The baud rate of the projector must be
the same as the baud rate of the connected computer. When there is a difference, consult ’Change Baudrate PC’ in this chapter.
• Projector Run Time: gives the total run time since the first start up. All projectors leave the factory with a run time of approxi-
mately 24 hours.
• Projector Serial number: indicates the fabrication number of the projector. This number can be useful when calling for technical
assistance.
